D-Link DWL-7620AP wireless access point 2200 Mbit/s White Power over Ethernet (PoE)

Model DWL-7620APEAN 790069438042

63 specifications

Overview

Brand: D-Link
Category: Wireless Access Point
Model: DWL-7620AP
Part number: DWL-7620AP
EAN / UPC: 790069438042, 790069438059, 790069438066
Also known as: D-Link DWL-7620AP wireless access point 2200 Mbit/s White Power over Ethernet (PoE)

63 specifications in 13 groups

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	2200 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 2.4835; 5.15 - 5.85 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3at
Channels quantity	165 channels
Automatic channel selection	Yes
MIMO	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Fast roaming	Yes
STA isolation (same VLAN)	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Quality of Service (QoS) support	Yes

Specification	Value
Security algorithms	AES, SNMP, SNMPv3, TKIP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
MAC address filtering	Yes
Number of SSID supported	32
Auto Wireless Distribution System (WDS)	Yes

Specification	Value
Web-based management	Yes

Specification	Value
Antennas quantity	2
Antenna gain level (max)	4 dBi

Specification	Value
Master (outer) cases per pallet (air)	24 pc(s)
Master (outer) cases per pallet (sea)	30 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	200.3 kg
Pallet gross weight (sea)	244.5 kg
Pallet gross width	120 cm
Pallet height (air)	144.7 cm
Pallet height (sea)	177.5 cm
Products per pallet (air)	120 pc(s)
Products per pallet (sea)	150 pc(s)
Products per shipping (inner) case	5 pc(s)
Shipping (inner) case gross weight	7.28 kg
Shipping (inner) case height	32.8 cm
Shipping (inner) case length	44.9 cm
Shipping (inner) case net weight	6.42 kg
Shipping (inner) case width	31.2 cm

Specification	Value
Certification	CE, FCC, IC, cUL+UL, CB, RCM, NCC, BSMI, UL2043, EN55032, EN55024, EN61000‑3‑2, EN61000‑3‑3, EN60601‑1‑2, EN301489‑1, EN301489‑17, EN300328, EN301893

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Storage relative humidity (H-H)	5 - 95%

Specification	Value
Harmonized System (HS) code	85176990
