Wireless AC1300 Wave 2 Outdoor IP67 Cloud Managed Access Point
Model DBA-3621PEAN 790069454448
31 specifications
- Speed1267 Mbit/s
- Weight1.38 kg
- ColourWhite
- 2.4 GHzYes
- Security algorithmsAES, SSID
- Ethernet LAN (RJ-45) ports1
Overview
- Speed
- 1267 Mbit/s
- Weight
- 1.38 kg
- Colour
- White
- 2.4 GHz
- Yes
- Security algorithms
- AES, SSID
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- D-Link
- Category
- Wireless Access Point
- Model
- DBA-3621P
- Part number
- DBA-3621P
- EAN / UPC
- 790069454448
- Also known as
- D-Link Wireless AC1300 Wave 2 Outdoor IP67 Cloud Managed Access Point
Specifications
31 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1267 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 400 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Cabling technology | 10/100/1000Base-T(X) |
| Flow control support | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | AES, SSID |
| MAC address filtering | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 13.5 W |
Design
| Specification | Value |
|---|---|
| Placement | In-wall, Pole |
| Product colour | White |
| International Protection (IP) code | IP67 |
Antenna
| Specification | Value |
|---|---|
| Antenna type | External |
| Antennas quantity | 2 |
| Antenna gain level (max) | 5 dBi |
| Antenna connector type | N-type |
Certificates
| Specification | Value |
|---|---|
| Certification | CE Class B FCC Class B UL IC Class B |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 79.5 mm |
| Height | 460 mm |
| Weight | 1.38 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -40 - 50 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
