D-Link DAP-3860 wireless access point 54 Mbit/s
Model DAP-3860
31 specifications
- ProcessorIntel IXP425
- Memory32 MB
- Speed54 Mbit/s
- ConnectivityRS-232
- Weight2.4 kg
- Management protocolsSNMPv2
Overview
- Processor
- Intel IXP425
- Memory
- 32 MB
- Speed
- 54 Mbit/s
- Connectivity
- RS-232
- Weight
- 2.4 kg
- Management protocols
- SNMPv2
- Brand
- D-Link
- Category
- Wireless Access Point
- Model
- DAP-3860
- Part number
- DAP-3860
- Also known as
- D-Link DAP-3860 wireless access point 54 Mbit/s
Specifications
31 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| Maximum data transfer rate | 54 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Frequency band | 5.7 - 5.8 GHz |
| Bandwidth | 2.4 GHz |
| Cabling technology | 10/100Base-T(X) |
| Modulation | 16-QAM, 64-QAM, BPSK, OFDM, QPSK |
Security
| Specification | Value |
|---|---|
| Security algorithms | 128-bit WEP, 152-bit WEP, 64-bit WEP, TKIP, WPA-PSK, WPA2-PSK |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMPv2 |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | RS-232 |
| Ethernet LAN (RJ-45) ports | 1 |
| WAN connection | Ethernet (RJ-45) |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Output power description | 19.3W |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna gain level (max) | 23 dBi |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor model | Intel IXP425 |
| Processor frequency | 533 MHz |
| Flash memory | 16 MB |
| Internal memory | 32 MB |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE, IC, C-Tick, NCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 320 x 320 x 27.5 mm |
| Weight | 2.4 kg |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 0.1 Gbit/s |
| Maximum operating distance | 4000 m |
| Networking features | 10/100 Base T |
| RF exposure | XA-632AH, AG-623C |
| Transmit power range | 27 - 30 dBmW |
| Wireless technology | 802.11 a |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | -30 - 70 °C |
