D-Link DAP-2680 + 5P650IRNG2 + SR18UB: Full Specifications

Overview

Speed: 1750 Mbit/s
Weight: 580 g
Colour: White
2.4 GHz: Yes
IPv4 & IPv6 features: IPv6 Telnet
Ethernet LAN (RJ-45) ports: 1

Brand: D-Link
Category: Wireless Access Point
Model: DAP-2680 + 5P650IRNG2 + SR18UB
Part number: DAP-2680-5P650-18U
Also known as: D-Link DAP-2680 + 5P650IRNG2 + SR18UB 1750 Mbit/s White Power over Ethernet (PoE)

Specifications

45 specifications in 11 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	1750 Mbit/s
Maximum data transfer rate (2.4 GHz)	450 Mbit/s
Maximum data transfer rate (5 GHz)	1300 Mbit/s
Frequency band	2.4 - 2.4835; 5.15 - 5.35; 5.47 - 5.85 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Wireless isolation	Yes
BeamForming	Yes
Transmitting power	26.5 dBmW

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SNMPv3, SSH, SSID, SSL/TLS, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
MAC address filtering	Yes
Service Set Identifier (SSID) features	SSID broadcast
Number of SSID supported	16
IGMP snooping	Yes
Auto Wireless Distribution System (WDS)	Yes

Protocols

Specification	Value
IPv4 & IPv6 features	IPv6 Telnet

Management features

Specification	Value
Web-based management	Yes
Command-line interface (CLI)	Yes
Syslog	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Output voltage	12 V
Output current	2 A

Design

Specification	Value
Placement	Table, Wall
Product colour	White
Housing material	Plastic
LED indicators	Power, Status

Antenna

Specification	Value
Antenna type	Internal
Antennas quantity	3
Antenna gain level (max)	4.2 dBi

Certificates

Specification	Value
Certification	FCC, UL, CE, FCC, UL

Weight & dimensions

Specification	Value
Width	190 mm
Depth	190 mm
Height	44.8 mm
Weight	580 g

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Storage relative humidity (H-H)	5 - 95%
