D-Link Wireless AC2300 Wave2 Dual-Band PoE Acess Point

Wireless AC2300 Wave2 Dual-Band PoE Acess Point

Model AC2300Part no. DAP-2682EAN 790069443756

44 specifications

Speed1700 Mbit/s
Weight551.6 g
ColourWhite
2.4 GHzYes
Security algorithms64-bit WEP, 128-bit WEP, WPA2
Management protocolsTelnet, SSH

See all specifications

Overview

Speed: 1700 Mbit/s
Weight: 551.6 g
Colour: White
2.4 GHz: Yes
Security algorithms: 64-bit WEP, 128-bit WEP, WPA2
Management protocols: Telnet, SSH

Brand: D-Link
Category: Wireless Access Point
Model: AC2300
Part number: DAP-2682
EAN / UPC: 790069443756, 790069454165
Also known as: D-Link Wireless AC2300 Wave2 Dual-Band PoE Acess Point

Specifications

44 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1700 Mbit/s
Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Maximum data transfer rate (5 GHz)	1700 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
Cabling technology	10/100/1000Base-T(X)
MIMO	Yes
MIMO type	Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Virtual LAN features	Multiple VXLAN (MUX VLAN)
Quality of Service (QoS) support	Yes
Mean time between failures (MTBF)	341897 h

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA2
MAC address filtering	Yes
Service Set Identifier (SSID) features	SSID broadcast
Number of SSID supported	16
Auto Wireless Distribution System (WDS)	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes

Protocols

Specification	Value
Management protocols	Telnet, SSH

Management features

Specification	Value
Web-based management	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2

Power

Specification	Value
Power over Ethernet (PoE)	Yes
AC input voltage	12 V
Input current	2.5 A
Power consumption (max)	15.5 W

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
LED indicators	Power, Status

Antenna

Specification	Value
Antenna type	Internal
Antenna gain level (max)	4.8 dBi

Certificates

Specification	Value
Certification	FCC, CE, UL

Weight & dimensions

Specification	Value
Width	190 mm
Depth	190 mm
Height	43.7 mm
Weight	551.6 g

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Storage relative humidity (H-H)	5 - 95%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
