AC1200 Wave 2
Model AC1200 Wave 2Part no. DAP-2620EAN 790069443749
36 specifications
- Speed867 Mbit/s
- Weight250.9 g
- ColourWhite
- 2.4 GHzYes
- Management protocolsSNMP v1 / v2c / v3
- Ethernet LAN (RJ-45) ports1
Overview
- Speed
- 867 Mbit/s
- Weight
- 250.9 g
- Colour
- White
- 2.4 GHz
- Yes
- Management protocols
- SNMP v1 / v2c / v3
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- D-Link
- Category
- Wireless Access Point
- Model
- AC1200 Wave 2
- Part number
- DAP-2620
- EAN / UPC
- 790069443749
- Also known as
- D-Link AC1200 Wave 2 867 Mbit/s White Power over Ethernet (PoE)
Specifications
36 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 867 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u |
| Maximum indoor range | 100 m |
Security
| Specification | Value |
|---|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2 |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP v1 / v2c / v3 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 12 V |
| Input current | 1 A |
| Power consumption (max) | 8 W |
Design
| Specification | Value |
|---|---|
| Placement | Ceiling, In-wall, Wall |
| Product colour | White |
| LED indicators | Power, Status |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna features | Integrated antenna |
| Antennas quantity | 2 |
| Antenna gain level (max) | 3 dBi |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 153.5 mm |
| Depth | 94.7 mm |
| Height | 35.8 mm |
| Weight | 250.9 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 65 °C |
| Operating altitude | 5 - 95 m |
| Storage relative humidity (H-H) | 10 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
