D-Link AC1200 1200 Mbit/s

AC1200 1200 Mbit/s

Model AC1200Part no. DAP-2662EAN 790069443633

46 specifications

Speed1200 Mbit/s
Weight316 g
2.4 GHzYes
Security featuresNetwork access point (NAP)
Management protocolsSSH, HTTPS, SNMP
Power consumption (typical)11 W

See all specifications

Overview

Speed: 1200 Mbit/s
Weight: 316 g
2.4 GHz: Yes
Security features: Network access point (NAP)
Management protocols: SSH, HTTPS, SNMP
Power consumption (typical): 11 W

Brand: D-Link
Category: Wireless Access Point
Model: AC1200
Part numbers: DAP-2662, DAP-2660, DAP-3662, DAP-3666
EAN / UPC: 790069443633, 790069404702, 790069404917, 790069406164 +21 more
Also known as: D-Link AC1200 1200 Mbit/s

Specifications

46 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1200 Mbit/s
Frequency band	2.4, 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
Modulation	PSK

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Security features	Network access point (NAP)
MAC address filtering	Yes

Protocols

Specification	Value
Management protocols	SSH, HTTPS, SNMP

Power

Specification	Value
Power consumption (typical)	11 W

Design

Specification	Value
Internal	No

Antenna

Specification	Value
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	4 dBi

Technical details

Specification	Value
Master (outer) cases per pallet (air)	96 pc(s)
Master (outer) cases per pallet (sea)	96 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	439.5 kg
Pallet gross weight (sea)	439.5 kg
Pallet gross width	120 cm
Pallet height (air)	2.05 m
Pallet height (sea)	2.05 m
Products per pallet (air)	480 pc(s)
Products per pallet (sea)	480 pc(s)
Products per shipping (inner) case	5 pc(s)
Shipping (inner) case gross weight	4.38 kg
Shipping (inner) case height	23.9 cm
Shipping (inner) case length	35.2 cm
Shipping (inner) case net weight	2.23 kg
Shipping (inner) case width	29 cm

Certificates

Specification	Value
Certification	FCC IC CE UL

Weight & dimensions

Specification	Value
Width	170 mm
Depth	170 mm
Height	28 mm
Weight	316 g

Packaging data

Specification	Value
Package width	204 mm
Package depth	269 mm
Package height	64 mm
Package weight	562.5 g

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Storage relative humidity (H-H)	5 - 95%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
