Cudy AC1200 Gigabit Wall-Plate Access Point: Full Specifications

Overview

Speed: 1167 Mbit/s
Weight: 261.2 g
Colour: White
2.4 GHz: Yes
Security algorithms: WPA, WPA2, WPA3
Ethernet LAN (RJ-45) ports: 5

Brand: Cudy
Category: Wireless Access Point
Model: AC1200 Gigabit Wall-Plate Access Point
Part number: AP1300 WALL
EAN / UPC: 6971690793432
Also known as: Cudy AC1200 Gigabit Wall-Plate Access Point 1167 Mbit/s White Power over Ethernet (PoE)

Specifications

49 specifications in 15 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Ethernet LAN data rates	1000,10,100 Mbit/s
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.3at, IEEE 802.11k, IEEE 802.11v
Bluetooth	No
MIMO	Yes
MIMO type	Multi User MIMO
VLAN support	Yes
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	WPA, WPA2, WPA3
Parental control	Yes
IGMP snooping	Yes

Protocols

Specification	Value
DHCP server	Yes

Management features

Specification	Value
Cloud-managed	Yes
Syslog	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	5
USB 2.0 ports quantity	0
WAN connection	Ethernet (RJ-45), Wi-Fi

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Passive PoE
Power consumption (typical)	4 W
Power consumption (max)	12 W

Design

Specification	Value
Placement	Wall
Product colour	White
LED indicators	System

Antenna

Specification	Value
Antenna type	Internal
Antenna direction type	Omni-directional
Antennas quantity	2

Performance

Specification	Value
Flash memory	16 MB

Technical details

Specification	Value
Products per shipping (inner) case	50 pc(s)

Weight & dimensions

Specification	Value
Width	143 mm
Depth	86 mm
Height	27.6 mm
Weight	261.2 g

Packaging data

Specification	Value
Package width	152 mm
Package depth	39.5 mm
Package height	90 mm
Package weight	362.9 g

Packaging content

Specification	Value
AC adapter included	No
PoE adapter included	No
Mounting kit	Yes
Quick start guide	Yes
Bundled software	Cudy Software

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C

Logistics data

Specification	Value
Country of origin	China
