MeetingBar A30-025
Model A30-025Part no. 1206649EAN 841885115331
58 specifications
- Display20.3 cm (8")
- Resolution1280 x 800 pixels
- ProcessorSnapdragon
- TypeVideo collaboration bar
- OSAndroid 10
- ColourBlack
Overview
- Display
- 20.3 cm (8")
- Resolution
- 1280 x 800 pixels
- Processor
- Snapdragon
- Type
- Video collaboration bar
- OS
- Android 10
- Colour
- Black
- Brand
- Yealink
- Category
- Video Conferencing System
- Model
- A30-025
- Part number
- 1206649
- EAN / UPC
- 841885115331, 5715063262702, 6938818315020
- Also known as
- Yealink MeetingBar A30-025
Specifications
58 specifications in 15 groups
Performance
| Specification | Value |
|---|---|
| Product type | Video collaboration bar |
| Bluetooth | Yes |
| Product colour | Black |
| Auto framing | Yes |
| Meeting features | Add participates, Calendar, Content sharing, Hold/Resume, One-click join, Whiteboard |
| PTZ control | Yes |
Video
| Specification | Value |
|---|---|
| Video codecs | H.264 High profile, H.264 SVC, H.264 |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 1 |
| Audio system full duplex | Yes |
| Echo cancellation | Yes |
| RMS rated power | 5 W |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-C |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Line-in | Yes |
| Line-out | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | Yes |
| Networking standards | IEEE 802.1x |
| VLAN support | Yes |
| Security algorithms | 256-bit AES, EAP-MD5, EAP-TTLS, PEAP, SRTP, TLS |
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8 MP |
| Camera type | Dual camera |
| Second camera resolution | 8 MP |
| Field of view (tele) | 90° |
| Field of view (wide) | 120° |
Display
| Specification | Value |
|---|---|
| Display diagonal | 20.3 cm (8") |
| Display resolution | 1280 x 800 pixels |
| Touchscreen | Yes |
Microphone
| Specification | Value |
|---|---|
| Microphone mute | Yes |
| Number of microphone arrays | 8 |
Computer system
| Specification | Value |
|---|---|
| Processor family | Snapdragon |
| Processor model | 845 |
| Operating system installed | Android 10 |
Features
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| DC output voltage | 48 V |
| DC output current | 0.7 A |
| Power consumption (idle) | 13 W |
| Power consumption (typical) | 10.5 W |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, RoHS, REACH, ISO 9001, CCC, NOM |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 700 mm |
| Depth | 98 mm |
| Height | 121 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | HDMI, LAN (RJ-45) |
| Networking cable length | 3 m |
| HDMI cable length | 1.8 m |
| AC adapter included | Yes |
| Quick start guide | Yes |
