PanaCast 55 VBS
Model PanaCast 55 VBSPart no. 8900-239EAN 5706991035223
78 specifications
- Display25.6 cm (10.1")
- Resolution1920 x 1200 pixels
- TypeGroup video conferencing system
- Weight2.26 kg
- ColourBlack
- HD type4K Ultra HD
Overview
- Display
- 25.6 cm (10.1")
- Resolution
- 1920 x 1200 pixels
- Type
- Group video conferencing system
- Weight
- 2.26 kg
- Colour
- Black
- HD type
- 4K Ultra HD
- Brand
- Jabra
- Category
- Video Conferencing System
- Model
- PanaCast 55 VBS
- Part numbers
- 8900-239, 8900-231
- EAN / UPC
- 5706991035223, 5706991035162
- Also known as
- Jabra PanaCast 55 VBS video conferencing system Ethernet LAN Group video conferencing system
Specifications
78 specifications in 14 groups
Performance
| Specification | Value |
|---|---|
| Product type | Group video conferencing system |
| Number of cameras | 3 |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Product colour | Black |
| Proximity sensor | Yes |
| Temperature sensor | Yes |
| Humidity sensor | Yes |
| AirPlay | Yes |
| Wall mountable | Yes |
| PTZ control | Yes |
Video
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum video resolution | 3840 x 2160 pixels |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 4 |
| Tweeter | Yes |
| Number of tweeter drivers | 2 |
| Tweeter diameter | 2 cm |
| Woofer | Yes |
| Number of woofer drivers | 2 |
| Woofer diameter | 5 cm |
| Frequency range | 80 - 20000 Hz |
| Audio beamforming | Yes |
| Echo cancellation | Yes |
| Noise reduction | Yes |
| RMS rated power | 20 W |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Power over Ethernet (PoE) ports quantity | 1 |
| AUX out | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Networking standards | IEEE 802.3af |
| Supported network protocols | IPv4, IPv6 |
| Auto MDIX IEEE | Yes |
| DHCP client | Yes |
| Static IP | Yes |
| Web-based management | Yes |
Camera
| Specification | Value |
|---|---|
| Digital zoom | 6x |
| Camera resolution | 3840 x 1080 pixels |
| Horizontal field of view | 180° |
| Vertical field of view | 54° |
| Camera privacy shutter | Yes |
Display
| Specification | Value |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1920 x 1200 pixels |
| Touchscreen | Yes |
Microphone
| Specification | Value |
|---|---|
| Microphone sensitivity | -37 dB |
| Microphone frequency | 100 - 16000 Hz |
| Number of microphones | 8 |
Features
| Specification | Value |
|---|---|
| Telepresence | No |
| People counting | Yes |
| Cable lock slot | Yes |
| Cable management | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Maximum operating altitude | 4876.8 m |
| Operating relative humidity (H-H) | 15 - 80% |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| DC output voltage | 12 V |
| DC output current | 5 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Monitor dimensions (WxDxH) | 248 x 156 x 85 mm |
| Monitor weight | 958 g |
| Width | 730 mm |
| Depth | 146 mm |
| Height | 77 mm |
| Weight | 2.26 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1065 mm |
| Package depth | 210 mm |
| Package height | 175 mm |
| Package weight | 5.76 kg |
Packaging content
| Specification | Value |
|---|---|
| Monitor included | Yes |
| Cables included | HDMI, AC |
| Wall mounting kit | Yes |
| AC adapter included | Yes |
