Yealink M600-0051 video conferencing system

M600-0051 video conferencing system

20 MP Ethernet LAN Group video conferencing system

Model M600-0051Part no. 1103950EAN 6938818306134

88 specifications

Display33.8 cm (13.3")
Resolution1920 x 1080 pixels
Storage16 GB
TypeGroup video conferencing system
ColourBlack
HD type4K Ultra HD

See all specifications

Overview

Display: 33.8 cm (13.3")
Resolution: 1920 x 1080 pixels
Storage: 16 GB
Type: Group video conferencing system
Colour: Black
HD type: 4K Ultra HD

Brand: Yealink
Category: Video Conferencing System
Model: M600-0051
Part number: 1103950
EAN / UPC: 6938818306134
Also known as: Yealink M600-0051 video conferencing system 20 MP Ethernet LAN Group video conferencing system

Specifications

88 specifications in 16 groups

Performance

Specification	Value
Product type	Group video conferencing system
Number of cameras	2
Bluetooth	Yes
Bluetooth version	4.2
Product colour	Black
Auto framing	Yes
Auto-tracking	Yes
Tracking modes	Presenter mode
Meeting features	Whiteboard

Video

Specification	Value
HD type	4K Ultra HD
Maximum video resolution	3840 x 2160 pixels
HD-Ready	Yes
Supported video modes	360p, 540p, 720p, 1080p, 2160p
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160
Maximum frame rate	30 fps
Resolution at capture speed	1280x720@30fps, 1920x1080@30fps, 3840x2160@30fps
Video formats supported	H.239, H.263, H.263+, H.264, H.265
Streaming capability	Yes
Dual stream	H.239 (H.323)/BFCP (SIP)
Video codecs	H.264 SVC, H.265, H.264 High Profile, H.264, H.263, H.263+

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
Audio system full duplex	Yes
Audio beamforming	Yes
Automatic gain control	Yes
Microphone pick-up range	6 m
Noise reduction	Yes
Voice codecs	AJB, CNG, G.711, G.722.1, G.722.1C, G.729, PLC
Speaker power	5 W

Memory

Specification	Value
Total storage capacity	16 GB

Ports & interfaces

Specification	Value
HDMI ports quantity	2
HDMI output ports quantity	2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Line-in	Yes
Line-out	Yes
Reset slot	Yes

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards	IEEE 802.1p, IEEE 802.1x
Security algorithms	256-bit AES, HTTPS, SRTP, TLS

Camera

Specification	Value
Megapixel (approx.)	20 MP
Camera type	Dual camera
Second camera resolution	8 MP
Zoom capability	Yes
Optical zoom	3.5x
Digital zoom	3x
Combined zoom	10x
Sensor type	CMOS
Image sensor size	1"
Field of view (FOV) angle	133°
Field of view (tele)	90°
PTZ motors	4x e-PTZ camera
Camera privacy shutter	Yes
Face tracking	Yes
Communication protocol	H.323 / SIP

Display

Specification	Value
Display	IPS
Display diagonal	33.8 cm (13.3")
Display resolution	1920 x 1080 pixels
Touchscreen	Yes
Touchscreen type	Capacitive

Microphone

Specification	Value
Number of microphone arrays	8

Computer system

Specification	Value
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Firmware upgradeable	Yes

Sustainability

Specification	Value
Sustainability compliance	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 95%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C

Power

Specification	Value
Power source type	AC
AC input voltage	100 - 240 V
DC output voltage	48 V
DC output current	0.7 A
Power consumption (idle)	13 W
Power consumption (max)	16 W
Power consumption (typical)	15 W

Certificates

Specification	Value
Compliance certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight & dimensions

Specification	Value
Width	700 mm
Depth	98 mm
Height	121 mm

Packaging content

Specification	Value
Wall mounting kit	Yes
Speaker included	Yes
Camera included	Yes
Microphone included	Yes
Remote control included	Yes
Packaging content	• MeetingEye 600 Codec (integrate codec/camera/microphone/speaker) • VCR20 Remote Control • Wall Bracket • Wireless Presentation Pod(WPP20) • CTP20 touch controller
