Viewsonic TeamJoin TRS10-UB

TeamJoin TRS10-UB

Model TeamJoin TRS10-UBPart no. TRS10-UBEAN 766907027778

69 specifications

Display25.6 cm (10.1")
Resolution1920 x 1200 pixels
ProcessorIntel® Core™ i3
Memory8000 MB
Storage128 GB
TypeVideo collaboration bar

See all specifications

Overview

Display: 25.6 cm (10.1")
Resolution: 1920 x 1200 pixels
Processor: Intel® Core™ i3
Memory: 8000 MB
Storage: 128 GB
Type: Video collaboration bar

Brand: Viewsonic
Category: Video Conferencing System
Model: TeamJoin TRS10-UB
Part number: TRS10-UB
EAN / UPC: 766907027778
Also known as: Viewsonic TeamJoin TRS10-UB video conferencing system 12 MP Ethernet LAN Video collaboration bar

Specifications

69 specifications in 16 groups

Performance

Specification	Value
Product type	Video collaboration bar
Bluetooth	Yes
Bluetooth version	5.3
Product colour	Black
Auto framing	Yes
PTZ control	Yes

Video

Specification	Value
HD type	2K Ultra HD
Maximum video resolution	3804 x 2160 pixels
Supported graphics resolutions	320 x 240, 352 x 288, 480 x 270, 640 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 960 x 540, 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160

Audio

Specification	Value
Built-in speaker(s)	Yes
Noise reduction	Yes

Memory

Specification	Value
Internal memory	8000 MB
Internal memory type	DDR4
Storage media type	SSD
Total storage capacity	128 GB

Ports & interfaces

Specification	Value
HDMI ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes

Camera

Specification	Value
Megapixel (approx.)	12 MP
Camera type	Single camera
Zoom capability	Yes
Digital zoom	5x
Sensor type	CMOS
Image sensor size	1/2.3"
Horizontal field of view	109°
Vertical field of view	74.4°
Diagonal field of view	117.8°
Communication protocol	UVC 1.1

Display

Specification	Value
Built-in display	Yes
Display	LED
Display diagonal	25.6 cm (10.1")
Display resolution	1920 x 1200 pixels
Touchscreen	Yes
Touchscreen type	Capacitive
Display brightness	300 cd/m²

Microphone

Specification	Value
Number of microphone arrays	6

Computer system

Specification	Value
Processor family	Intel® Core™ i3
Processor model	i3-1220P
VESA mounting	Yes
Operating system installed	Windows 11 IoT Enterprise
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1
Mac operating systems supported	Yes
Other operating systems supported	Android, ChromeOS

Features

Specification	Value
Motion sensor	Yes

Logistics data

Specification	Value
Harmonized System (HS) code	8525890000

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	111.9 W

Weight & dimensions

Specification	Value
Interface module dimensions (W x D x H)	230 x 275.5 x 43 mm
Remote control dimensions (W x H x D)	244.8 x 160 x 98 mm
Speaker dimensions (WxDxH)	461 x 93 x 76.4 mm
Weight	8.3 kg

Packaging data

Specification	Value
Package width	565 mm
Package depth	550 mm
Package height	215 mm
Package weight	10.2 kg

Packaging content

Specification	Value
Cables included	AC, USB Type-C
Power cable length	1.8 m
Wall mounting kit	Yes
AC adapter included	Yes
Mounting kit	Yes
Quick start guide	Yes
Remote control included	Yes
Screws included	Yes
