DocCAM 4K HDBT Document Camera
Model 999-99680-000EAN 840077508715
50 specifications
- TypeGroup video conferencing system
- Weight1.91 kg
- ColourWhite
- HD typeFull HD
- Power over Ethernet (PoE) ports quantity1
- Ethernet LANYes
Overview
- Type
- Group video conferencing system
- Weight
- 1.91 kg
- Colour
- White
- HD type
- Full HD
- Power over Ethernet (PoE) ports quantity
- 1
- Ethernet LAN
- Yes
- Brand
- Vaddio
- Category
- Video Conferencing System
- Model
- 999-99680-000
- Part number
- 999-99680-000
- EAN / UPC
- 840077508715
- Also known as
- Vaddio DocCAM 4K HDBT Document Camera
Specifications
50 specifications in 14 groups
Performance
| Specification | Value |
|---|---|
| Product type | Group video conferencing system |
| Product colour | White |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| PTZ control | No |
| Wireless range | 100 m |
Video
| Specification | Value |
|---|---|
| HD type | Full HD |
| Maximum video resolution | 3840 x 2160 pixels |
| Supported video modes | 2160p |
| Maximum frame rate | 30 fps |
| Resolution at capture speed | 3840x2160@30fps |
| Streaming capability | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) ports quantity | 1 |
| RS-232 ports | 1 |
Interface module
| Specification | Value |
|---|---|
| Interface module HDMI ports quantity | 1 |
| Interface module RS-232 ports quantity | 2 |
| Interface module Ethernet LAN (RJ-45) ports | 1 |
| Interface module DC input port | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8.57 MP |
| Optical zoom | 30x |
| Sensor type | CMOS |
| Image sensor size | 1/2.5" |
| Wide end viewing angle (normal mode) | 70.2° |
| Tele end viewing angle (normal mode) | 3.1° |
| Focus adjustment | Auto/Manual |
| PTZ motors | No Motors Manual |
| Remote control interface | IR Wireless |
| Recommended luminance | 100 lx |
| Aperture number of steps | 16 |
| White balance | ATW, Auto, Indoor, Manual, One push, Outdoor |
| Back Light Compensation (BLC) | Yes |
| Gain control type | Auto/Manual |
| Sync system | Internal |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
Features
| Specification | Value |
|---|---|
| Invertible | No |
| Tri-Synchronous Motion Technology | No |
| Control method | IR remote, Joystick, RS-232, Telnet, Web UI |
| OneLink compatibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Power
| Specification | Value |
|---|---|
| Current | 1.36 A |
| DC input voltage | 48 V |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), TAA |
| Certification | FCC,TAA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 203.2 mm |
| Depth | 203.2 mm |
| Height | 108 mm |
| Weight | 1.91 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 5.9 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | RS-232, USB |
| Remote control included | Yes |
