MAXHUB XBar V70 Kit

XBar V70 Kit

Model XBar V70 KitPart no. V70 KITEAN 6927433608174

74 specifications

Display29.5 cm (11.6")
Resolution1920 x 1080 pixels
Memory16 MB
Storage256 GB
TypeGroup video conferencing system
OSAndroid 13

See all specifications

Overview

Display: 29.5 cm (11.6")
Resolution: 1920 x 1080 pixels
Memory: 16 MB
Storage: 256 GB
Type: Group video conferencing system
OS: Android 13

Brand: MAXHUB
Category: Video Conferencing System
Model: XBar V70 Kit
Part numbers: V70 KIT, XBAR V70 KIT
EAN / UPC: 6927433608174
Also known as: MAXHUB XBar V70 Qua-eyes 4K Microsoft Teams Rooms MDEP Videobar

Specifications

74 specifications in 15 groups

Performance

Specification	Value
Product type	Group video conferencing system
Number of cameras	4
Bluetooth	Yes
Bluetooth version	5.2
Product colour	Black, Grey
Auto framing	Yes
Auto-tracking	Yes

Video

Specification	Value
HD type	4K Ultra HD
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	640 x 360, 800 x 600 (SVGA), 960 x 540, 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160
Video formats supported	H.264, M-JPEG, YUY2

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
Frequency range	80 - 20000 Hz
Microphone pick-up range	10 m
Noise reduction	Yes
RMS rated power	40 W

Memory

Specification	Value
Internal memory	16 MB
Internal memory type	DDR4
Storage media type	SSD
Total storage capacity	256 GB

Ports & interfaces

Specification	Value
HDMI ports quantity	3
HDMI input ports quantity	1
HDMI output ports quantity	2
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	3
DC-in jack	Yes
AUX out	Yes

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Camera

Specification	Value
Megapixel (approx.)	50 MP
Camera type	Quad camera
Zoom capability	Yes
Combined zoom	8x
Image sensor size	1/1.55"
Camera privacy shutter	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Display

Specification	Value
Built-in display	Yes
Display	LED
Display diagonal	29.5 cm (11.6")
Display resolution	1920 x 1080 pixels
Touchscreen	Yes
Touchscreen type	Capacitive
Display brightness	300 cd/m²
Anti-glare screen	Yes

Microphone

Specification	Value
Microphone sensitivity	-36 dB
Microphone frequency	20 - 16000 Hz
Sound pressure level (max)	88 dB
Number of microphone arrays	16

Features

Specification	Value
Motion sensor	Yes

Computer system

Specification	Value
Operating system installed	Android 13

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-20 - 60 °C

Power

Specification	Value
Power source type	AC
AC input voltage	100 - 240 V
DC output voltage	19 V
DC output current	4.5 A

Packaging data

Specification	Value
Package width	290 mm
Package depth	985 mm
Package height	275 mm
Package weight	11.7 kg

Packaging content

Specification	Value
Cables included	Power, USB Type-C, LAN (RJ-45), HDMI
Power cable length	1.5 m
Networking cable length	7.5 m
HDMI cable length	3 m
Quick start guide	Yes
