Logi Dock Focus Room kit Teams
Model Logi Dock Focus Room kit TeamsPart no. 78462174
45 specifications
- Weight1.09 kg
- ColourGraphite
- Number of persons1 person(s)
- HD type4K Ultra HD
- Built-in speaker(s)Yes
- HDMI ports quantity1
Overview
- Weight
- 1.09 kg
- Colour
- Graphite
- Number of persons
- 1 person(s)
- HD type
- 4K Ultra HD
- Built-in speaker(s)
- Yes
- HDMI ports quantity
- 1
- Brand
- Lenovo
- Category
- Video Conferencing System
- Model
- Logi Dock Focus Room kit Teams
- Part number
- 78462174
- Also known as
- Lenovo Logi Dock Focus Room kit Teams video conferencing system 1 person(s) 13 MP Personal video conferencing system
Specifications
45 specifications in 11 groups
Performance
| Specification | Value |
|---|---|
| Product type | Personal video conferencing system |
| Number of persons | 1 person(s) |
| Bluetooth | Yes |
| Product colour | Graphite |
Video
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum video resolution | 3840 x 2160 pixels |
| Supported video modes | 1080p, 720p, 2160p |
| Supported graphics resolutions | 4096 x 2160, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720) |
| Maximum frame rate | 90 fps |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Frequency range | 60 - 20000 Hz |
| Audio beamforming | Yes |
| Driver diameter | 5.5 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| USB connector type | Mini-USB A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 3 |
| DC-in jack | Yes |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 13 MP |
| Camera type | Single camera |
| Zoom capability | Yes |
| Digital zoom | 5x |
| Horizontal field of view | 82.1° |
| Vertical field of view | 52.2° |
| Diagonal field of view | 90° |
| Camera privacy shutter | Yes |
Microphone
| Specification | Value |
|---|---|
| Number of microphones | 6 |
Features
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Computer system
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Yes |
| Mac operating systems supported | MacOS |
| Mobile operating systems supported | Android, iOS |
| Other operating systems supported | ChromeOS |
Power
| Specification | Value |
|---|---|
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 100 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Speaker dimensions (WxDxH) | 102 x 27 x 27 mm |
| Speaker weight | 63 g |
| Width | 160 mm |
| Depth | 207 mm |
| Height | 88 mm |
| Weight | 1.09 kg |
