Barco ClickShare Hub Core
Barco

ClickShare Hub Core

Model ClickShare Hub CorePart no. R9861711USB1EAN 5415334054738

53 specifications
  • Display25.6 cm (10.1")
  • Resolution1280 x 800 pixels
  • Noise25 dB
  • Weight720 g
  • ColourBlack
  • BluetoothYes
See all specifications

Overview

Display
25.6 cm (10.1")
Resolution
1280 x 800 pixels
Noise
25 dB
Weight
720 g
Colour
Black
Bluetooth
Yes
Brand
Barco
Model
ClickShare Hub Core
Part numbers
R9861711USB1, R9461811EU, R9861711EUB1
EAN / UPC
5415334054738, 5415334056527, 8592978719975, 8717472603050
Also known as
Barco ClickShare Hub Core video conferencing system Ethernet LAN Video conferencing service management system

Specifications

53 specifications in 14 groups

Performance

Product typeVideo conferencing service management system
BluetoothYes
Bluetooth version5.3
Product colourBlack
Noise level25 dB

Video

HD type5K Ultra HD
Maximum video resolution5120 x 2160 pixels
Supported graphics resolutions1280 x 800 (WXGA), 5120 x 2160

Ports & interfaces

HDMI output ports quantity1
HDMI version2.0
USB 2.0 Type-C ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity3
USB Type-C DisplayPort Alternate ModeYes
Ethernet LAN (RJ-45) ports1
DisplayPort version1.4

Buttons

Presentation button includedYes

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Networking standardsIEEE 802.15.1

Display

Built-in displayYes
Display diagonal25.6 cm (10.1")
Display resolution1280 x 800 pixels
Contrast ratio (typical)1000:1
TouchscreenYes
Viewing angle, horizontal80°
Viewing angle, vertical80°

Features

Cable lock slotYes
Cable lock slot typeKensington
Maximum operating distance30 m

Computer system

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterp
Mac operating systems supportedMac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia

Logistics data

Country of originChina

Operational conditions

Operating relative humidity (H-H)0 - 85%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)0 - 90%
Storage temperature (T-T)-20 - 60 °C

Power

Power source typeUSB
Power consumption (max)140 W
USB Power Delivery (USB PD)Yes
USB Power Delivery up to180 W

Certificates

Compliance certificatesCE, Federal Communications Commission (FCC)

Weight & dimensions

Monitor dimensions (WxDxH)187.9 x 76.9 x 254.5 mm
Monitor weight820 g
Width180 mm
Depth180 mm
Height37 mm
Weight720 g
Receiver dimensions (WxDxH)63 x 161.3 x 16 mm

Packaging content

Camera includedNo
Packaging contentClickShare Hub Core Base Unit, 1 ClickShare Hub Button 5th Gen, Mounting disc, Safety manual, Quick setup guide, Control Panel, ClickShare 10M 20W USB-C AOC cable, L-Shape mounting plate, Round base, Screw pack, Quick setup guide, USB-C cable lock kit
