AVer VC520 Pro Teams

VC520 Pro Teams

Model VC520 Pro TeamsPart no. 61U0100000APEAN 4719552126675

63 specifications

TypeGroup video conferencing system
Weight6.25 kg
HD typeFull HD
Noise reductionYes
USB connector typeUSB Type-B
Megapixel (approx.)2 MP

See all specifications

Overview

Type: Group video conferencing system
Weight: 6.25 kg
HD type: Full HD
Noise reduction: Yes
USB connector type: USB Type-B
Megapixel (approx.): 2 MP

Brand: AVer
Category: Video Conferencing System
Model: VC520 Pro Teams
Part number: 61U0100000AP
EAN / UPC: 4719552126675
Also known as: AVer VC520 Pro Teams video conferencing system 2 MP Ethernet LAN Group video conferencing system

Specifications

63 specifications in 14 groups

Performance

Specification	Value
Product type	Group video conferencing system
Wall mountable	Yes
Pan range	-170 - 170°
Tilt angle range	-30 - 90°
Tripod mounting supported	Yes

Video

Specification	Value
HD type	Full HD
Supported graphics resolutions	320 x 240, 480 x 360, 640 x 360, 640 x 480 (VGA), 800 x 448, 848 x 480, 960 x 540, 1280 x 720 (HD 720), 1600 x 900, 1920 x 1080 (HD 1080)
Maximum frame rate	60 fps
Video formats supported	H.264, M-JPEG, YUV

Audio

Specification	Value
Noise reduction	Yes
Speaker power	6 W

Ports & interfaces

Specification	Value
USB connector type	USB Type-B
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	1
Headphone outputs	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Supported network protocols	RTSP, RTMP

Camera

Specification	Value
Megapixel (approx.)	2 MP
Optical zoom	12x
Combined zoom	18x
Focal length range	3.9-47.3 mm
Field of view (FOV) angle	82°
Wide Dynamic Range (WDR)	Yes
Number of camera presets	10
Aperture range (F-F)	1.8 - 2.8
Closest focusing distance	1.5 m
White balance	Auto, Manual
Back Light Compensation (BLC)	Yes

Microphone

Specification	Value
Microphone colour	Black
Microphone sensitivity	-34 dB
Microphone frequency	120 - 16000 Hz
Microphone Total Harmonic Distortion (THD)	1%

Features

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington

Logistics data

Specification	Value
Country of origin	Taiwan
Harmonized System (HS) code	8517691000
Products per master (outer) case	2 pc(s)
Products per pallet	40 pc(s)

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 80%
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C

Power

Specification	Value
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Current	5 A
DC input voltage	12 V

Weight & dimensions

Specification	Value
Microphone dimensions (WxHxD)	220 x 181.5 x 49.5 mm
Camera dimensions (WxDxH)	142.7 x 153 x 182 mm
Width	251 mm
Depth	348 mm
Height	308 mm
Weight	6.25 kg

Packaging data

Specification	Value
Package width	366 mm
Package depth	525 mm
Package height	330 mm
Package weight	6.7 kg

Packaging content

Specification	Value
Cables included	AC, AUX, LAN (RJ-45), USB
Power cable length	1.8 m
Networking cable length	10 m
AC adapter included	Yes
Mounting kit	Yes
Camera included	Yes
Remote control included	Yes
