USB 3.0 to VGA Adapter - On-Board Driver Installation
1920x1200
Model USB32VGAVEAN 065030860833
37 specifications
- Memory8 MB
- Weight9.3 g
- ColourBlack
- USB version3.2 Gen 1 (3.1 Gen 1)
- Minimum processor familyCore i5
- Width25 mm
Overview
- Memory
- 8 MB
- Weight
- 9.3 g
- Colour
- Black
- USB version
- 3.2 Gen 1 (3.1 Gen 1)
- Minimum processor family
- Core i5
- Width
- 25 mm
- Brand
- StarTech.com
- Category
- USB Graphics Adapter
- Model
- USB32VGAV
- Part number
- USB32VGAV
- EAN / UPC
- 065030860833, 4058829181604, 5054629522615, 6136005131655
- Also known as
- StarTech.com USB 3.0 to VGA Adapter - On-Board Driver Installation - 1920x1200
Specifications
37 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-A |
| USB connector gender | Male |
| DVI output | No |
| HDMI output | No |
| DisplayPort output | No |
| Number of displays supported | 1 |
| VGA (D-Sub) output | Yes |
| Internal memory | 8 MB |
| Maximum resolution | 1920 x 1200 pixels |
| Supported graphics resolutions | 1280 x 800, 1280 x 960, 1600 x 900, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 800 x 600 (SVGA) |
| Supported video modes | 480p, 720p, 1080p |
| Output colour depth | 16/32 bit |
| Chipset | Fresco - FL2000DX |
| USB pass-through | No |
| Certification | FCC, CE, REACH |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Integrated USB cable | Yes |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows |
| Minimum processor family | Core i5 |
| Minimum processor speed | 2.4 GHz |
| Minimum RAM | 4 GB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 25 mm |
| Depth | 195 mm |
| Height | 12 mm |
| Weight | 9.3 g |
| USB cable length | 0.139 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 40 - 50% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 143 mm |
| Package depth | 172 mm |
| Package height | 30 mm |
| Package weight | 92 g |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
