JCA153G-N USB-C® to 4K HDMI™ Adapter
Model JCA153GPart no. JCA153G-NEAN 847626002427
54 specifications
- Weight25 g
- ColourGrey, White
- USB version2.0/3.2 Gen 1 (3.1 Gen 1)
- Power consumption (max)0.7 W
- Mac compatibilityYes
- Width23 mm
Overview
- Weight
- 25 g
- Colour
- Grey, White
- USB version
- 2.0/3.2 Gen 1 (3.1 Gen 1)
- Power consumption (max)
- 0.7 W
- Mac compatibility
- Yes
- Width
- 23 mm
- Brand
- j5create
- Category
- USB Graphics Adapter
- Model
- JCA153G
- Part number
- JCA153G-N
- EAN / UPC
- 847626002427, 24712795081927, 4712795081923
- Also known as
- j5create JCA153G-N USB-C® to 4K HDMI™ Adapter
Specifications
54 specifications in 10 groups
Performance
| Specification | Value |
|---|---|
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-C |
| USB connector gender | Male |
| DVI output | No |
| HDMI output | Yes |
| DisplayPort output | No |
| Number of displays supported | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Maximum resolution | 3840 x 2160 pixels |
| Refresh rate at maximum resolution | 60 Hz |
| Maximum resolution (HDMI) | 3840 x 2160 pixels |
| Current | 0.14 A |
| Resolution at refresh rate | 4k @ 30Hz 4k @ 60Hz |
Design
| Specification | Value |
|---|---|
| Product colour | Grey, White |
| Housing material | Aluminium |
| Integrated USB cable | Yes |
| Cable type | USB-C |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 0.7 W |
| Output voltage | 5 V |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Other operating systems supported | Android |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 23 mm |
| Depth | 68 mm |
| Height | 14 mm |
| Weight | 25 g |
| USB cable length | 0.145 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 71 °C |
Packaging data
| Specification | Value |
|---|---|
| Package width | 145 mm |
| Package depth | 95 mm |
| Package height | 25 mm |
| Package weight | 52 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Batteries included | No |
| Cables included | USB Type-C |
| Quick installation guide | Yes |
| Packaging content | 1 x JCA153G USB Type-C to 4K HDMI Adapter, 1 x Quick Installation Guide |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 2 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 20 pc(s) |
| Master (outer) case GTIN (EAN/UPC) | 24712795081927 |
| Master (outer) case width | 225 mm |
| Master (outer) case length | 321 mm |
| Master (outer) case height | 180 mm |
| Master (outer) case gross weight | 1.79 kg |
| Products per shipping (inner) case | 5 pc(s) |
| Shipping (inner) case width | 10.5 cm |
| Shipping (inner) case length | 15 cm |
| Shipping (inner) case height | 16 cm |
| Country of origin | Taiwan |
| Export Control Classification Number (ECCN) | EAR99 |
