USB-C to Dual Displayport 1.4 Adapter, USB Type-C Multi-Monitor MST Hub, Dual 5K
60Hz DP Laptop Display Extender / Splitter, HDR, Extra-Long Built-
Model MST14CD122DPEAN 065030884372
33 specifications
- ColourGrey
- USB connector typeUSB Type-C
- USB cable length0.3 m
- Operating temperature (T-T)0 - 40 °C
- Compliance certificatesCE, RoHS
Overview
- Colour
- Grey
- USB connector type
- USB Type-C
- USB cable length
- 0.3 m
- Operating temperature (T-T)
- 0 - 40 °C
- Compliance certificates
- CE, RoHS
- Brand
- StarTech.com
- Category
- USB Graphics Adapter
- Model
- MST14CD122DP
- Part number
- MST14CD122DP
- EAN / UPC
- 065030884372
- Also known as
- StarTech.com USB-C to Dual Displayport 1.4 Adapter, USB Type-C Multi-Monitor MST Hub, Dual 5K 60Hz DP Laptop Display Extender / Splitter, HDR, Extra-Long Built-
Specifications
33 specifications in 8 groups
Performance
| Specification | Value |
|---|---|
| USB connector type | USB Type-C |
| USB connector gender | Male |
| USB connector form factor | Straight |
| DVI output | No |
| HDMI output | No |
| DisplayPort output | Yes |
| High Dynamic Range (HDR) supported | Yes |
| DisplayPorts quantity | 2 |
| Number of displays supported | 2 |
| HDCP | Yes |
| HDCP version | 2.2 |
| DisplayPort version | 1.4 |
| Maximum resolution | 4096 x 2160 pixels |
| Refresh rate at maximum resolution | 60 Hz |
| Audio output channels | 2.0 channels |
| Chipset | Synaptics - VMM5220, VIA/VLI - VL103 |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| Housing material | Plastic |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 |
Weight & dimensions
| Specification | Value |
|---|---|
| USB cable length | 0.3 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 142 mm |
| Package depth | 170 mm |
| Package height | 30 mm |
| Package weight | 108.8 g |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
| Sustainability compliance | Yes |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 70 pc(s) |
| Master (outer) case width | 473 mm |
| Master (outer) case length | 331 mm |
| Master (outer) case height | 440 mm |
