USB C to HDMI Adapter - 4K
60Hz Video, HDR10 - USB-C to HDMI 2.0b Adapter Dongle - USB Type-C DP Alt Mode to HDMI Monitor/Display/TV - USB C to HDM
Model CDP2HD4K60HEAN 065030879712
34 specifications
- Weight25 g
- ColourBlack
- USB connector typeUSB Type-C
- Width150 mm
- Operating temperature (T-T)5 - 35 °C
- Compliance certificatesRoHS
Overview
- Weight
- 25 g
- Colour
- Black
- USB connector type
- USB Type-C
- Width
- 150 mm
- Operating temperature (T-T)
- 5 - 35 °C
- Compliance certificates
- RoHS
- Brand
- StarTech.com
- Category
- USB Graphics Adapter
- Model
- CDP2HD4K60H
- Part number
- CDP2HD4K60H
- EAN / UPC
- 065030879712
- Also known as
- StarTech.com USB C to HDMI Adapter - 4K 60Hz Video, HDR10 - USB-C to HDMI 2.0b Adapter Dongle - USB Type-C DP Alt Mode to HDMI Monitor/Display/TV - USB C to HDM
Specifications
34 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| USB connector type | USB Type-C |
| USB connector gender | Male |
| DVI output | No |
| HDMI output | Yes |
| DisplayPort output | No |
| Number of displays supported | 1 |
| HDMI version | 2.0b |
| DisplayPort version | 1.4 |
| Maximum resolution | 3840 x 2160 pixels |
| Refresh rate at maximum resolution | 60 Hz |
| Audio output channels | 7.1 channels |
| Chipset | MegaChips - MCDP2900 |
| Data transfer rate (max) | 18 Gbit/s |
| Certification | CE, FCC, REACH |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Plastic |
| Integrated USB cable | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 25 mm |
| Height | 11 mm |
| Weight | 25 g |
| USB cable length | 0.1 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 25 - 60% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 106 mm |
| Package depth | 199 mm |
| Package height | 16 mm |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 250 pc(s) |
| Master (outer) case width | 513 mm |
| Master (outer) case length | 342 mm |
| Master (outer) case height | 230 mm |
| Harmonized System (HS) code | 84733020 |
