USB-C to HDMI Adapter with 4K
30Hz - Black
Model CDP2HDEAN 065030862615
36 specifications
- Weight22 g
- ColourBlack
- USB version3.2 Gen 2 (3.1 Gen 2)
- Width23 mm
- Operating temperature (T-T)0 - 45 °C
- Compliance certificatesCE, RoHS
Overview
- Weight
- 22 g
- Colour
- Black
- USB version
- 3.2 Gen 2 (3.1 Gen 2)
- Width
- 23 mm
- Operating temperature (T-T)
- 0 - 45 °C
- Compliance certificates
- CE, RoHS
- Brand
- StarTech.com
- Category
- USB Graphics Adapter
- Model
- CDP2HD
- Part number
- CDP2HD
- EAN / UPC
- 065030862615, 5054629963258
- Also known as
- StarTech.com USB-C to HDMI Adapter with 4K 30Hz - Black
Specifications
36 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| USB connector type | USB Type-C |
| USB connector gender | Male |
| USB connector form factor | Straight |
| DVI output | No |
| HDMI output | Yes |
| DisplayPort output | No |
| Number of displays supported | 1 |
| HDMI version | 1.4 |
| Maximum resolution | 3840 x 2160 pixels |
| Refresh rate at maximum resolution | 30 Hz |
| Supported graphics resolutions | 1024 x 768 (XGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1280 x 720 (HD 720), 2560 x 1600 (WQXGA), 3840 x 2160 |
| Supported video modes | 1080p, 720p |
| Audio output channels | 7.1 channels |
| Chipset | Parade - PS171, STMicroelectronics - STM32F072CBU6 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Integrated USB cable | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 23 mm |
| Depth | 147 mm |
| Height | 9 mm |
| Weight | 22 g |
| USB cable length | 0.12 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 85% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 197 mm |
| Package depth | 104 mm |
| Package height | 18 mm |
| Package weight | 30 g |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
| Sustainability compliance | Yes |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 120 pc(s) |
| Master (outer) case width | 516 mm |
| Master (outer) case length | 344 mm |
| Master (outer) case height | 227 mm |
| Harmonized System (HS) code | 84733020 |
