K34680WW
Model CV5000DPPart no. K34680WWEAN 085896346807
43 specifications
- Weight-8 g
- ColourBlack
- USB connector typeUSB Type-C
- Mac compatibilityYes
- Width54 mm
- Operating temperature (T-T)0 - 45 °C
Overview
- Weight
- -8 g
- Colour
- Black
- USB connector type
- USB Type-C
- Mac compatibility
- Yes
- Width
- 54 mm
- Operating temperature (T-T)
- 0 - 45 °C
- Brand
- Kensington
- Category
- USB Graphics Adapter
- Model
- CV5000DP
- Part number
- K34680WW
- EAN / UPC
- 085896346807, 5028252633925, 5028252633932
- Also known as
- Kensington K34680WW
Specifications
43 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| USB connector type | USB Type-C |
| USB connector gender | Male |
| USB connector form factor | Straight |
| DVI output | No |
| HDMI output | No |
| DisplayPort output | Yes |
| DisplayPorts quantity | 1 |
| Number of displays supported | 1 |
| HDCP | Yes |
| HDCP version | 1.4/2.2 |
| DisplayPort version | 1.4 |
| Maximum resolution | 7680 x 4320 pixels |
| Refresh rate at maximum resolution | 30 Hz |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Plastic |
| Integrated USB cable | Yes |
| Cable type | Round cable |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterp |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Other operating systems supported | ChromeOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 54 mm |
| Depth | 22 mm |
| Height | 11 mm |
| Weight | -8 g |
| USB cable length | 0.121 m |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 25 mm |
| Package depth | 119 mm |
| Package height | 79 mm |
| Package weight | 50 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 10 pc(s) |
| Master (outer) case width | 105 mm |
| Master (outer) case length | 253 mm |
| Master (outer) case height | 135 mm |
| Master (outer) case gross weight | 500 g |
| Master (outer) case net weight | 353 g |
| Minimum order quantity | 1 pc(s) |
| Country of origin | China, Vietnam |
