Zyxel XGS1930-52HP + GRATIS NWA1123-AC Pro Access point

Zyxel XGS1930-52HP + GRATIS NWA1123-AC Pro Access point

Model XGS1930-52HP + GRATIS NWA1123-AC Pro Access pointPart no. XGS1930-52HP-EU0103FEAN 4718937610211

69 specifications

Memory512 MB
Noise28.4 dB
Type1U
Weight5.1 kg
ColourBlack
Switch typeManaged

See all specifications

Overview

Memory: 512 MB
Noise: 28.4 dB
Type: 1U
Weight: 5.1 kg
Colour: Black
Switch type: Managed

Brand: Zyxel
Category: Network Switch
Model: XGS1930-52HP + GRATIS NWA1123-AC Pro Access point
Part number: XGS1930-52HP-EU0103F
EAN / UPC: 4718937610211
Also known as: Zyxel XGS1930-52HP + GRATIS NWA1123-AC Pro Access point Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

Specifications

69 specifications in 15 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L3
Web-based management	Yes
MIB support	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	4
Fiber optic connector	SFP+
Power connector	AC-in jack

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring	Yes
IP routing	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Port-based VLAN, Voice VLAN
Number of VLANs	4000

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	176 Gbit/s
Forwarding rate	130.9 Mpps
Static route	Yes
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP client, DHCP relay, DHCPv6 relay
Access Control List (ACL)	Yes
IGMP snooping	Yes
Authentication	Guest VLAN, MAC-based authentication, Port-based authentication
Authentication type	RADIUS
Loop protection	Yes
Password protection	Yes
SSH/SSL support	Yes
Security algorithms	802.1x RADIUS, HTTPS, SHA-2, SNMPv3, SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes

Protocols

Specification	Value
Management protocols	SNMP
GARP VLAN Registration Protocol (GVRP)	Yes

Design

Specification	Value
Rack mounting	Yes
Form factor	1U
Product colour	Black
LED indicators	Yes
Electromagnetic compatibility	FCC 15 A, CE A, BSMI EMC

Performance

Specification	Value
Internal memory	512 MB
Flash memory	32 MB
Noise level	28.4 dB
Mean time between failures (MTBF)	494960 h

Power

Specification	Value
Power supply included	Yes
Number of power supply units	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	498.4 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	48
Total Power over Ethernet (PoE) budget	375 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	10 - 95%
Heat dissipation	1699.544 BTU/h

Weight & dimensions

Specification	Value
Width	441 mm
Depth	330 mm
Height	44 mm
Weight	5.1 kg

Packaging content

Specification	Value
Cables included	AC
Rack mount kit	Yes

Certificates

Specification	Value
Certification	RoHS
