D-Link 24-Port 10/100/1000 Switch + 4 Combo SFP Ports

D-Link 24-Port 10/100/1000 Switch + 4 Combo SFP Ports

Model 24-Port 10/100/1000 Switch + 4 Combo SFP PortsPart no. DGS-3024EAN 790069273681

18 specifications

Speed1 Gbit/s
Weight3.8 kg
Basic switching RJ-45 Ethernet ports quantity24
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
MAC address table8000 entries
Management protocolsTelnet, RMON, SNMP v1/2/3

See all specifications

Overview

Speed: 1 Gbit/s
Weight: 3.8 kg
Basic switching RJ-45 Ethernet ports quantity: 24
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
MAC address table: 8000 entries
Management protocols: Telnet, RMON, SNMP v1/2/3

Brand: D-Link
Category: Network Switch
Model: 24-Port 10/100/1000 Switch + 4 Combo SFP Ports
Part number: DGS-3024
EAN / UPC: 790069273681, 790069273889, 7900692736818
Also known as: D-Link 24-Port 10/100/1000 Switch + 4 Combo SFP Ports

Specifications

18 specifications in 8 groups

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24

Network

Specification	Value
Networking standards	IEEE 802.1d, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	48 Gbit/s
Maximum data transfer rate	1 Gbit/s

Protocols

Specification	Value
Management protocols	Telnet, RMON, SNMP v1/2/3
Switching protocols	TFTP, DHCP
Data link protocols	Ethernet, Fast Ethernet, Gibabit Ethernet

Design

Specification	Value
Safety	CSA International

Other features

Specification	Value
Management platform	CLI/Console, Web-based HTTP
Data transfer rate	1000 Mbit/s
Dimensions (WxDxH)	30.91 x 44.09 x 4.39 mm
I/O ports	24x 10/100/1000 Ethernet Ports 4x Combo SFP Expansion Slots

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Weight	3.8 kg
