VLHDMIMAT4X444 matrix switcher AV matrix switcher Built-in display
65 W
Model VLHDMIMAT4X444EAN 5704174240549
44 specifications
- TypeAV matrix switcher
- Weight3.4 kg
- Housing colourBlack
- Built-in displayYes
- HDMI input ports quantity4
- Power consumption (max)65 W
Overview
- Type
- AV matrix switcher
- Weight
- 3.4 kg
- Housing colour
- Black
- Built-in display
- Yes
- HDMI input ports quantity
- 4
- Power consumption (max)
- 65 W
- Brand
- Vivolink
- Category
- Matrix Switcher
- Model
- VLHDMIMAT4X444
- Part number
- VLHDMIMAT4X444
- EAN / UPC
- 5704174240549
- Also known as
- Vivolink VLHDMIMAT4X444 matrix switcher AV matrix switcher Built-in display 65 W
Specifications
44 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Product type | AV matrix switcher |
| Maximum resolution | 4096 x 2160 pixels |
| Bandwidth | 18 Gbit/s |
| Audio channels | 7.1 |
| HDCP | Yes |
| HDCP version | 2.2 |
| 3D | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Extended display identification data (EDID) | Yes |
| EDID management | Yes |
| Audio formats supported | LPCM |
| Supported chroma subsampling | 4:4:4, 4:2:0 |
Design
| Specification | Value |
|---|---|
| Housing colour | Black |
| Housing material | Metal |
| Rack mounting | Yes |
| Control type | Buttons |
| LED indicators | Yes |
| On/off switch | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 4 |
| HDMI output ports quantity | 4 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 4 |
| Digital audio optical out | 4 |
| USB connector type | USB Type-A |
| USB ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 5 |
| RS-232 ports | 5 |
| Analog audio output terminal ports | 4 |
| Remote (IR) input | 5 |
| Remote (IR) output | 5 |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 65 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 55 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 436.4 mm |
| Depth | 356.6 mm |
| Height | 44 mm |
| Weight | 3.4 kg |
| Package weight | 3.5 kg |
