8x8 HDMI 4K60 Matrix
Model 38334EAN 4002888383349
39 specifications
- TypeAV matrix switcher
- Weight2.83 kg
- Housing colourBlack
- Built-in displayYes
- HDMI input ports quantity8
- Power consumption (max)43 W
Overview
- Type
- AV matrix switcher
- Weight
- 2.83 kg
- Housing colour
- Black
- Built-in display
- Yes
- HDMI input ports quantity
- 8
- Power consumption (max)
- 43 W
- Brand
- Lindy
- Category
- Matrix Switcher
- Model
- 38334
- Part number
- 38334
- EAN / UPC
- 4002888383349
- Also known as
- Lindy 8x8 HDMI 4K60 Matrix
Specifications
39 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Product type | AV matrix switcher |
| Maximum resolution | 3840 x 2160 pixels |
| Bandwidth | 18 Gbit/s |
| HDCP | Yes |
| HDCP version | 2.2 |
| EDID management | Yes |
| Audio formats supported | DTS, LPCM |
Design
| Specification | Value |
|---|---|
| Housing colour | Black |
| Housing material | Metal |
| Control type | Buttons |
| Certification | CP65 |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display type | OLED |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI input ports quantity | 8 |
| HDMI output ports quantity | 8 |
| HDMI version | 2.0b |
| RJ-45 input ports | 1 |
| RS-232 ports | 1 |
| Audio (L/R) out | 8 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 43 W |
| Input current | 5 A |
| Output voltage | 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 45 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA |
| Sustainability compliance | Yes |
| Warranty period | 2 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 200 mm |
| Height | 45 mm |
| Weight | 2.83 kg |
| Package type | Box |
| Package width | 510 mm |
| Package depth | 328 mm |
| Package height | 95 mm |
| Package weight | 4.06 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
