IDATA HDMI-KVM372
Model IDATA HDMI-KVM372EAN 8059018368628
30 specifications
- ConnectivityWired
- TypeTransmitter & receiver
- ColourBlack
- Transmitter video port typeHDMI
- RJ-45 ports quantity (receiver)1
- USB port typeUSB Type-A
Overview
- Connectivity
- Wired
- Type
- Transmitter & receiver
- Colour
- Black
- Transmitter video port type
- HDMI
- RJ-45 ports quantity (receiver)
- 1
- USB port type
- USB Type-A
- Brand
- Techly
- Category
- KVM Extender
- Model
- IDATA HDMI-KVM372
- Part number
- IDATA HDMI-KVM372
- EAN / UPC
- 8059018368628
- Also known as
- Techly IDATA HDMI-KVM372 KVM extender Transmitter & receiver
Specifications
30 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 70 m |
| Cable types supported | Cat6, Cat6a, Cat7 |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Product colour | Black |
| Material | Metal |
| Plug and Play | Yes |
| LED indicators | Yes |
| Electrostatic Discharge (ESD) protection | Yes |
| Certification | EC, RoHS |
| Audio support | Yes |
Transmitter
| Specification | Value |
|---|---|
| Transmitter video port type | HDMI |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
Receiver
| Specification | Value |
|---|---|
| RJ-45 ports quantity (receiver) | 1 |
| Receiver local keyboard/mouse port type | USB |
| Receiver local video port type | HDMI |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port type | USB Type-A |
| USB 2.0 ports quantity | 3 |
| RJ-45 ports quantity | 2 |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 5 V |
| AC adapter output current | 1 A |
| DC-in jack | Yes |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| HDCP | No |
| Extended display identification data (EDID) | Yes |
