USB True 4K HDMI Cat 6 KVM Extender (4K @ 70 m / FHD @ 100 m)
ATEN

USB True 4K HDMI Cat 6 KVM Extender (4K @ 70 m / FHD @ 100 m)

Model CE801Part no. CE801-AT-GEAN 4710469349850

56 specifications
  • ConnectivityWired
  • TypeAV transmitter & transceiver
  • ColourBlack
  • Transmitter video port typeHDMI
  • RJ-45 ports quantity (receiver)1
  • USB port typeUSB Type-A
See all specifications

Overview

Connectivity
Wired
Type
AV transmitter & transceiver
Colour
Black
Transmitter video port type
HDMI
RJ-45 ports quantity (receiver)
1
USB port type
USB Type-A
Brand
ATEN
Category
KVM Extender
Model
CE801
Part numbers
CE801-AT-G, CE801-AT-U
EAN / UPC
4710469349850
Also known as
ATEN USB True 4K HDMI Cat 6 KVM Extender (4K @ 70 m / FHD @ 100 m)

Specifications

56 specifications in 12 groups

Features

TypeAV transmitter & transceiver
Connectivity technologyWired
Maximum transfer distance100 m
Cable types supportedCat6, Cat6a
Rack mountingYes
Maximum digital resolution3840 x 2160 pixels
Maximum refresh rate60 Hz
KVM port selectionPush-buttons
Supported resolutions640 x 480, 800 x 600, 1024 x 768, 1280 x 800, 1280 x 1024, 1400 x 1050, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 3840 x 2160
Product colourBlack
MaterialMetal
LED indicatorsLink, Power, Status

Transmitter

Transmitter video port typeHDMI
Transmitter local video portYes
Transmitter local video port typeHDMI
Transmitter local keyboard/mouse port typeUSB
RJ-45 ports quantity (transmitter)1
Transmitter USB Type-B ports quantity1

Receiver

RJ-45 ports quantity (receiver)1
Receiver local keyboard/mouse port typeUSB
Receiver local video port typeHDMI

Ports & interfaces

USB port typeUSB Type-A
USB 2.0 ports quantity4
RS-232 ports2

Power

AC adapter output voltage5 V
Power consumption (transmitter) (max)2.59 W
Power consumption (receiver) (max)1.88 W
DC-in jackYes

Weight & dimensions

Transmitter width8.21 cm
Transmitter depth12.8 cm
Transmitter height2.5 cm
Transmitter weight320 g
Receiver width8.15 cm
Receiver depth12.8 cm
Receiver height2.5 cm
Receiver weight310 g

Packaging data

Package weight1.38 kg

Packaging content

AC adapter includedYes
Cables includedUSB Type-A to USB Type-B
ManualYes
Mounting bracket(s) includedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Other features

HDCPYes
HDCP version2.3
Extended display identification data (EDID)Yes

Technical details

Package volume3029.9026 cm³

Logistics data

Country of originChina
Harmonized System (HS) code85176200
Master (outer) case net weight5.27 kg
Master (outer) case volume19566.941 cm³
Master (outer) case width300 mm
Master (outer) case length336 mm
Master (outer) case height194 mm
Master (outer) case gross weight6.99 kg
