CE800B
Model CE800BPart no. CE800B-AT-GEAN 4710423774933
52 specifications
- ConnectivityWired
- TypeTransmitter & receiver
- ColourBlack
- Transmitter video port typeVGA
- Receiver local keyboard/mouse port typeUSB
- USB port typeUSB Type-A/USB Type-B
Overview
- Connectivity
- Wired
- Type
- Transmitter & receiver
- Colour
- Black
- Transmitter video port type
- VGA
- Receiver local keyboard/mouse port type
- USB
- USB port type
- USB Type-A/USB Type-B
- Brand
- ATEN
- Category
- KVM Extender
- Model
- CE800B
- Part number
- CE800B-AT-G
- EAN / UPC
- 4710423774933, 672792108884, 999992352306, 4710423775770 +1 more
- Also known as
- ATEN AT-CE800B
Specifications
52 specifications in 11 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 250 m |
| Cable types supported | Cat5e |
| Maximum digital resolution | 1920 x 1200 pixels |
| Maximum analog resolution | 1920 x 1200 pixels |
| KVM port selection | Push-buttons |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
Transmitter
| Specification | Value |
|---|---|
| Transmitter video port type | VGA |
| Transmitter local video port | Yes |
| Transmitter local video port type | VGA |
| Number of displays supported | 1 |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
Receiver
| Specification | Value |
|---|---|
| Receiver local keyboard/mouse port type | USB |
| Receiver local video port type | VGA |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port type | USB Type-A/USB Type-B |
| RJ-45 ports quantity | 1 |
| PC Audio in | Yes |
| PC Audio out | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (transmitter) (max) | 6 W |
| Power consumption (receiver) (max) | 6 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter width | 20.2 cm |
| Transmitter depth | 8.16 cm |
| Transmitter height | 2.63 cm |
| Transmitter weight | 490 g |
| Receiver width | 20.2 cm |
| Receiver depth | 8.63 cm |
| Receiver height | 2.63 cm |
| Receiver weight | 510 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 98 mm |
| Package depth | 325 mm |
| Package height | 210 mm |
| Package weight | 2.03 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | KVM, USB |
| Manual | Yes |
| Quick installation guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Other features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
| Compliance certificates | RoHS, WEEE |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
| Master (outer) case net weight | 8.6 kg |
| Master (outer) case width | 342 mm |
| Master (outer) case length | 512 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 10.9 kg |
| Products per master (outer) case | 5 pc(s) |
