USB HDMI Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)
ATEN

USB HDMI Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)

Model CE824Part no. CE824-AT-GEAN 4711581520653

57 specifications
  • ConnectivityWired
  • TypeTransmitter & receiver
  • Weight2.91 kg
  • ColourBlack
  • Transmitter video port typeHDMI
  • Receiver USB Type-A ports quantity4
See all specifications

Overview

Connectivity
Wired
Type
Transmitter & receiver
Weight
2.91 kg
Colour
Black
Transmitter video port type
HDMI
Receiver USB Type-A ports quantity
4
Brand
ATEN
Category
KVM Extender
Model
CE824
Part numbers
CE824-AT-G, CE824-AT-U
EAN / UPC
4711581520653
Also known as
ATEN USB HDMI Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)

Specifications

57 specifications in 12 groups

Features

TypeTransmitter & receiver
Connectivity technologyWired
Maximum transfer distance150 m
Cable types supportedCat6, Cat6a
Rack mountingYes
Maximum digital resolution4096 x 2160 pixels
KVM port selectionPush-buttons
Product colourBlack
MaterialMetal
LED indicatorsPower, Link
Electrostatic Discharge (ESD) protectionYes

Transmitter

Transmitter video port typeHDMI
Transmitter local video portYes
Transmitter local video port typeHDMI
Transmitter USB Type-B ports quantity1

Receiver

Receiver USB Type-A ports quantity4
Receiver local keyboard/mouse port typeUSB
Receiver local video port typeHDMI
Receiver local video ports quantity2

Ports & interfaces

RJ-45 ports quantity2
RS-232 ports2
PC Audio inYes
PC Audio outYes

Power

Power consumption (transmitter) (max)5.98 W
Power consumption (receiver) (max)10.32 W
DC-in jackYes

Weight & dimensions

Transmitter width15.6 cm
Transmitter depth17.4 cm
Transmitter height2.88 cm
Transmitter weight790 g
Receiver width15.6 cm
Receiver depth2.88 cm
Receiver height17.4 cm
Receiver weight820 g

Packaging data

Package width131 mm
Package depth540 mm
Package height233 mm
Package weight3.48 kg

Packaging content

AC adapter includedYes
Cables includedHDMI, Audio, USB Type-A to USB Type-B
ManualYes
Mounting bracket(s) includedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Other features

HDCPYes
Extended display identification data (EDID)Yes

Technical details

Package volume16480.404716544 cm³
Weight2.91 kg

Logistics data

Country of originTaiwan
Harmonized System (HS) code85176200
Master (outer) case net weight2.91 kg
Master (outer) case volume21011.100171264 cm³
Master (outer) case width247 mm
Master (outer) case length556 mm
Master (outer) case height153 mm
Master (outer) case gross weight3.88 kg
