140m 4 Port USB 2.0 Cat.6 Extender
Model 42710EAN 4002888427104
34 specifications
- ConnectivityWired
- TypeTransmitter & receiver
- ColourBlack
- RJ-45 ports quantity (transmitter)1
- USB 2.0 ports quantity5
- AC adapter output voltage5 V
Overview
- Connectivity
- Wired
- Type
- Transmitter & receiver
- Colour
- Black
- RJ-45 ports quantity (transmitter)
- 1
- USB 2.0 ports quantity
- 5
- AC adapter output voltage
- 5 V
- Brand
- Lindy
- Category
- KVM Extender
- Model
- 42710
- Part number
- 42710
- EAN / UPC
- 4002888427104
- Also known as
- Lindy 140m 4 Port USB 2.0 Cat.6 Extender
Specifications
34 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 140 m |
| Cable types supported | Cat5e, Cat6 |
| Product colour | Black |
| Material | Aluminium |
| LED indicators | Yes |
| Certification | CE, FCC, RoHS & REACH, CP65 |
Transmitter
| Specification | Value |
|---|---|
| RJ-45 ports quantity (transmitter) | 1 |
Receiver
| Specification | Value |
|---|---|
| RJ-45 ports quantity (receiver) | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 5 |
| USB data transfer rates | 480 Mbit/s |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 5 V |
| AC adapter output current | 2.6 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter width | 12 cm |
| Transmitter depth | 6.7 cm |
| Transmitter height | 2.7 cm |
| Transmitter weight | 190 g |
| Receiver width | 13 cm |
| Receiver depth | 6.7 cm |
| Receiver height | 2.7 cm |
| Receiver weight | 210 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 240 mm |
| Package depth | 150 mm |
| Package height | 55 mm |
| Package weight | 1.32 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB Type-A to USB Type-B |
| Manual | Yes |
| Included power plug types | EU, UK, US |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
