5K DP Dual Display KVM over IP Tx
Model KX9980T-AX-E
31 specifications
- ConnectivityWired
- TypeTransmitter
- ColourBlack
- Transmitter video port typeDisplayPort
- USB port typeUSB Type-A/USB Type-B
- Power consumption (transmitter) (max)36.6 W
Overview
- Connectivity
- Wired
- Type
- Transmitter
- Colour
- Black
- Transmitter video port type
- DisplayPort
- USB port type
- USB Type-A/USB Type-B
- Power consumption (transmitter) (max)
- 36.6 W
- Brand
- ATEN
- Category
- KVM Extender
- Model
- KX9980T-AX-E
- Part number
- KX9980T-AX-E
- Also known as
- ATEN 5K DP Dual Display KVM over IP Tx
Specifications
31 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter |
| Connectivity technology | Wired |
| Maximum digital resolution | 5120 x 2880 pixels |
| Maximum refresh rate | 240 Hz |
| Colour depth | 12 bit |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
| Certification | RoHS |
Transmitter
| Specification | Value |
|---|---|
| Transmitter video port type | DisplayPort |
| Transmitter local video port | Yes |
| Transmitter local video port type | DisplayPort |
| Number of displays supported | 2 |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
| Transmitter USB Type-B ports quantity | 2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port type | USB Type-A/USB Type-B |
| PC Audio in | Yes |
| PC Audio out | Yes |
| SFP/SFP+ slots quantity | 2 |
Power
| Specification | Value |
|---|---|
| Power consumption (transmitter) (max) | 36.6 W |
| DC-in jack | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter width | 16.3 cm |
| Transmitter depth | 21.5 cm |
| Transmitter height | 4.2 cm |
| Transmitter weight | 1.43 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Harmonized System (HS) code | 85176200 |
