KE9950ATC KVM extender Transmitter & receiver
Model KE9950ATC
37 specifications
- ConnectivityWired
- TypeTransmitter & receiver
- ColourBlack
- Transmitter video port typeDisplayPort
- RJ-45 ports quantity (receiver)1
- USB port typeUSB Type-A/USB Type-B
Overview
- Connectivity
- Wired
- Type
- Transmitter & receiver
- Colour
- Black
- Transmitter video port type
- DisplayPort
- RJ-45 ports quantity (receiver)
- 1
- USB port type
- USB Type-A/USB Type-B
- Brand
- ATEN
- Category
- KVM Extender
- Model
- KE9950ATC
- Part number
- KE9950ATC
- Also known as
- ATEN KE9950ATC KVM extender Transmitter & receiver
Specifications
37 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 30 Hz |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
Transmitter
| Specification | Value |
|---|---|
| Transmitter video port type | DisplayPort |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
Receiver
| Specification | Value |
|---|---|
| RJ-45 ports quantity (receiver) | 1 |
| Receiver local keyboard/mouse port type | USB |
| Receiver local video port type | DisplayPort |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port type | USB Type-A/USB Type-B |
| USB data transfer rates | 480 Mbit/s |
| RJ-45 ports quantity | 3 |
| RS-232 ports | 3 |
| Installed SFP+ modules quantity | 2 |
| PC Audio in | Yes |
| PC Audio out | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter width | 16.3 cm |
| Transmitter depth | 21.5 cm |
| Transmitter height | 4.18 cm |
| Transmitter weight | 1.15 kg |
| Receiver width | 17.2 cm |
| Receiver depth | 22.8 cm |
| Receiver height | 5.48 cm |
| Receiver weight | 1.27 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC, DVI, USB |
| Manual | Yes |
| Quick installation guide | Yes |
| Mounting bracket(s) included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
