4K HDMI&DP Quad KVM over IP Rx
Model KE8980MRPart no. KE8980MR-AX-EEAN 672792016714
30 specifications
- ConnectivityWired
- TypeReceiver
- ColourBlack
- Receiver local keyboard/mouse port typeUSB
- USB port typeUSB Type-A
- Power consumption (receiver) (max)33 W
Overview
- Connectivity
- Wired
- Type
- Receiver
- Colour
- Black
- Receiver local keyboard/mouse port type
- USB
- USB port type
- USB Type-A
- Power consumption (receiver) (max)
- 33 W
- Brand
- ATEN
- Category
- KVM Extender
- Model
- KE8980MR
- Part number
- KE8980MR-AX-E
- EAN / UPC
- 672792016714
- Also known as
- ATEN 4K HDMI&DP Quad KVM over IP Rx
Specifications
30 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Type | Receiver |
| Connectivity technology | Wired |
| Maximum digital resolution | 4096 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
Receiver
| Specification | Value |
|---|---|
| Receiver local keyboard/mouse port type | USB |
| Receiver local video ports quantity | 4 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port type | USB Type-A |
| USB 2.0 ports quantity | 4 |
| RJ-45 ports quantity | 2 |
Power
| Specification | Value |
|---|---|
| Power consumption (receiver) (max) | 33 W |
| DC-in jack | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Receiver width | 19 cm |
| Receiver depth | 20 cm |
| Receiver height | 4.18 cm |
| Receiver weight | 1.34 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 266 mm |
| Package depth | 383 mm |
| Package height | 115 mm |
| Package weight | 2.31 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Master (outer) case width | 365 mm |
| Master (outer) case length | 396 mm |
| Master (outer) case height | 294 mm |
| Master (outer) case gross weight | 7.6 kg |
