KE6940T-AX-U KVM extender Transmitter
Model KE6940T-AX-U
37 specifications
- ConnectivityWired
- TypeTransmitter
- ColourBlack
- Transmitter video port typeDVI-I
- RS-232 ports1
- AC adapter output voltage5 V
Overview
- Connectivity
- Wired
- Type
- Transmitter
- Colour
- Black
- Transmitter video port type
- DVI-I
- RS-232 ports
- 1
- AC adapter output voltage
- 5 V
- Brand
- ATEN
- Category
- KVM Extender
- Model
- KE6940T-AX-U
- Part number
- KE6940T-AX-U
- Also known as
- ATEN KE6940T-AX-U KVM extender Transmitter
Specifications
37 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter |
| Connectivity technology | Wired |
| Cable types supported | Cat5e |
| Rack mounting | Yes |
| Maximum digital resolution | 1920 x 1200 pixels |
| Colour depth | 24 bit |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
Transmitter
| Specification | Value |
|---|---|
| Transmitter video port type | DVI-I |
| Number of displays supported | 2 |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| RS-232 ports | 1 |
| PC Audio in | Yes |
| PC Audio out | Yes |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 5 V |
| Power consumption (transmitter) (max) | 8.91 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter width | 21.5 cm |
| Transmitter depth | 16.3 cm |
| Transmitter height | 4.18 cm |
| Transmitter weight | 1.15 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 207 mm |
| Package depth | 414 mm |
| Package height | 117 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | DVI, KVM |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Other features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case net weight | 6.51 kg |
| Master (outer) case width | 370 mm |
| Master (outer) case length | 427 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 8.12 kg |
