True 4K DP/HDMI Optical KVM 300m
ATEN

True 4K DP/HDMI Optical KVM 300m

Model CE980Part no. CE980-AT-EEAN 672792016509

47 specifications
  • ConnectivityWired
  • TypeTransmitter & receiver
  • ColourBlack
  • Transmitter video port typeDisplayPort
  • RJ-45 ports quantity (receiver)1
  • USB 2.0 ports quantity4
See all specifications

Overview

Connectivity
Wired
Type
Transmitter & receiver
Colour
Black
Transmitter video port type
DisplayPort
RJ-45 ports quantity (receiver)
1
USB 2.0 ports quantity
4
Brand
ATEN
Category
KVM Extender
Model
CE980
Part numbers
CE980-AT-E, CE980-AT-U, CE980-AT-G
EAN / UPC
672792016509, 4710469349621
Also known as
ATEN True 4K DP/HDMI Optical KVM 300m

Specifications

47 specifications in 10 groups

Features

TypeTransmitter & receiver
Connectivity technologyWired
Maximum transfer distance300 m
Rack mountingYes
Maximum digital resolution4096 x 2160 pixels
Product colourBlack
MaterialMetal
LED indicatorsYes

Transmitter

Transmitter video port typeDisplayPort
Transmitter local video portYes
Transmitter local video port typeHDMI
Transmitter local keyboard/mouse port typeUSB
RJ-45 ports quantity (transmitter)1

Receiver

RJ-45 ports quantity (receiver)1
Receiver local keyboard/mouse port typeUSB
Receiver local video port typeDisplayPort

Ports & interfaces

USB 2.0 ports quantity4
USB data transfer rates480 Mbit/s
PC Audio inYes
PC Audio outYes

Power

AC adapter output voltage12 DC
Power consumption (transmitter) (max)11.89 W
Power consumption (receiver) (max)9.49 W

Weight & dimensions

Transmitter width15.6 cm
Transmitter depth17.8 cm
Transmitter height2.88 cm
Transmitter weight850 g
Receiver width15.6 cm
Receiver depth17.8 cm
Receiver height2.88 cm
Receiver weight840 g

Packaging data

Package width131 mm
Package depth540 mm
Package height233 mm
Package weight3.56 kg

Packaging content

AC adapter includedYes
Cables includedDisplayPort
ManualYes
Mounting bracket(s) includedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Logistics data

Country of originTaiwan
Master (outer) case width247 mm
Master (outer) case length556 mm
Master (outer) case height153 mm
Master (outer) case gross weight4.13 kg
