CE920 KVM extender Transmitter & receiver
Model CE920EAN 672792008726
35 specifications
- ConnectivityWired
- TypeTransmitter & receiver
- ColourBlack
- Transmitter video port typeDisplayPort
- RJ-45 ports quantity (receiver)1
- USB 2.0 ports quantity4
Overview
- Connectivity
- Wired
- Type
- Transmitter & receiver
- Colour
- Black
- Transmitter video port type
- DisplayPort
- RJ-45 ports quantity (receiver)
- 1
- USB 2.0 ports quantity
- 4
- Brand
- ATEN
- Category
- KVM Extender
- Model
- CE920
- Part numbers
- CE920, CE920-AT-G
- EAN / UPC
- 672792008726, 672792013669, 4719264646775
- Also known as
- ATEN CE920 KVM extender Transmitter & receiver
Specifications
35 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 150 m |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum digital resolution | 4096 x 2160 pixels |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
| Certification | RoHS |
Transmitter
| Specification | Value |
|---|---|
| Transmitter video port type | DisplayPort |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
Receiver
| Specification | Value |
|---|---|
| RJ-45 ports quantity (receiver) | 1 |
| Receiver local keyboard/mouse port type | USB |
| Receiver local video port type | DisplayPort |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB data transfer rates | 480 Mbit/s |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 5 V |
| Power consumption (transmitter) (max) | 3.99 W |
| Power consumption (receiver) (max) | 6.74 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Transmitter width | 18.2 cm |
| Transmitter depth | 12.2 cm |
| Transmitter height | 2.87 cm |
| Transmitter weight | 630 g |
| Receiver width | 18.2 cm |
| Receiver depth | 12.2 cm |
| Receiver height | 2.87 cm |
| Receiver weight | 640 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | DisplayPort |
| Manual | Yes |
| Mounting bracket(s) included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
