CE840-AT-E KVM extender Transmitter & receiver
ATEN

CE840-AT-E KVM extender Transmitter & receiver

Model CE840-AT-E

47 specifications
  • ConnectivityWired
  • TypeTransmitter & receiver
  • ColourBlack
  • Transmitter video port typeHDMI
  • RJ-45 ports quantity (receiver)1
  • USB port typeUSB Type-B
See all specifications

Overview

Connectivity
Wired
Type
Transmitter & receiver
Colour
Black
Transmitter video port type
HDMI
RJ-45 ports quantity (receiver)
1
USB port type
USB Type-B
Brand
ATEN
Category
KVM Extender
Model
CE840-AT-E
Part number
CE840-AT-E
Also known as
ATEN CE840-AT-E KVM extender Transmitter & receiver

Specifications

47 specifications in 10 groups

Features

TypeTransmitter & receiver
Connectivity technologyWired
Maximum transfer distance100 m
Maximum digital resolution4096 x 2160 pixels
Supported resolutions4096 x 2160 3840 x 2160
Product colourBlack
MaterialMetal
LED indicatorsYes

Transmitter

Transmitter video port typeHDMI
Transmitter local video portYes
Transmitter local video port typeHDMI
RJ-45 ports quantity (transmitter)1
Transmitter USB Type-B ports quantity1

Receiver

RJ-45 ports quantity (receiver)1
Receiver local video port typeHDMI

Ports & interfaces

USB port typeUSB Type-B
RS-232 ports1

Power

Power consumption (transmitter) (max)7.36 W
Power consumption (receiver) (max)7.37 W
DC voltage12 V
DC-in jackYes

Weight & dimensions

Transmitter width15.6 cm
Transmitter depth17.8 cm
Transmitter height2.88 cm
Transmitter weight820 g
Receiver width15.6 cm
Receiver depth17.8 cm
Receiver height2.88 cm
Receiver weight810 g

Packaging data

Package width131 mm
Package depth540 mm
Package height233 mm
Package weight2.98 kg

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Other features

HDCPYes
HDCP version2.3
Bandwidth18 Gbit/s
Bandwidth600 MHz
Supported video modes480p, 600p, 768p, 800p, 900p, 1024p, 1080i, 1080p, 1440p, 2160p

Logistics data

Country of originTaiwan
Harmonized System (HS) code85176200
Master (outer) case width247 mm
Master (outer) case length556 mm
Master (outer) case height153 mm
Master (outer) case gross weight3.54 kg
