2 Port PCI Express PCIe SuperSpeed (5Gbps) USB 3.0 Card Adapter with UASP - LP4 Power
Model PEXUSB3S25EAN 898029656076
34 specifications
- Weight51 g
- Host interfacePCIe
- InternalYes
- ChipsetRenesas / NEC - µPD720202
- Operating temperature (T-T)0 - 50 °C
- Compliance certificatesRoHS
Overview
- Weight
- 51 g
- Host interface
- PCIe
- Internal
- Yes
- Chipset
- Renesas / NEC - µPD720202
- Operating temperature (T-T)
- 0 - 50 °C
- Compliance certificates
- RoHS
- Brand
- StarTech.com
- Category
- Interface Cards/Adapters
- Model
- PEXUSB3S25
- Part number
- PEXUSB3S25
- EAN / UPC
- 898029656076, 042111892686, 065030854603, 115971579728 +11 more
- Also known as
- StarTech.com 2 Port PCI Express PCIe SuperSpeed (5Gbps) USB 3.0 Card Adapter with UASP - LP4 Power
Specifications
34 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | USB 3.2 Gen 1 (3.1 Gen 1) |
| Expansion card form factor | Full-height / Low-profile |
| Expansion card standard | PCIe 2.0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Maximum cable length | 3 m |
| Certification | CE, FCC |
Features
| Specification | Value |
|---|---|
| Chipset | Renesas / NEC - µPD720202 |
| Data transfer rate (max) | 5 Gbit/s |
| UASP support | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 85% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 18 mm |
| Depth | 82 mm |
| Height | 120 mm |
| Weight | 51 g |
Packaging data
| Specification | Value |
|---|---|
| Cables included | SATA |
| Drivers included | Yes |
| Manual | Yes |
| Package width | 217 mm |
| Package depth | 148 mm |
| Package height | 37 mm |
| Package weight | 154 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Products per master (outer) case | 40 pc(s) |
| Master (outer) case width | 452 mm |
| Master (outer) case length | 383 mm |
| Master (outer) case height | 325 mm |
