StarTech.com 4 Port Native PCI Express RS232 Serial Adapter Card with 16550 UART

StarTech.com 4 Port Native PCI Express RS232 Serial Adapter Card with 16550 UART

Model PEX4S553EAN 7887117188332

33 specifications
  • Weight74 g
  • Host interfacePCIe
  • InternalYes
  • ChipsetASIX - MCS9904CV-AA
  • Operating temperature (T-T)0 - 50 °C
  • Compliance certificatesRoHS
See all specifications

Overview

Weight
74 g
Host interface
PCIe
Internal
Yes
Chipset
ASIX - MCS9904CV-AA
Operating temperature (T-T)
0 - 50 °C
Compliance certificates
RoHS
Brand
StarTech.com
Model
PEX4S553
Part number
PEX4S553
EAN / UPC
7887117188332, 065030843553, 851975716713, 887695416572 +8 more
Also known as
StarTech.com 4 Port Native PCI Express RS232 Serial Adapter Card with 16550 UART

Specifications

33 specifications in 9 groups

Ports & interfaces

Host interfacePCIe
Output interfaceSerial
Serial ports quantity4
Serial interface typeRS-232

Design

InternalYes
Mean time between failures (MTBF)26280 h
CertificationCE, FCC, REACH

Features

ChipsetASIX - MCS9904CV-AA
Baud rate128 Kbit/s
FIFO (First In, First Out)256 B
Data bits5, 6, 7, 8

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)5 - 85%

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supportedWindows Embedded POSReady 2009, Windows Embedded Standard 2009, Windows XP Embedded

Technical details

Compliance certificatesRoHS

Weight & dimensions

Width130 mm
Depth120 mm
Height19 mm
Weight74 g

Packaging data

Quantity1
Mounting brackets includedYes
Drivers includedYes
ManualYes
Package width141 mm
Package depth170 mm
Package height30 mm
Package weight230 g

Logistics data

Harmonized System (HS) code84733020
