StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS
Model PEX1S952LPEAN 4058829151430
36 specifications
- Weight48 g
- ColourGreen
- Host interfacePCIe
- InternalYes
- ChipsetPLX/Oxford - OXPCIe952
- Operating temperature (T-T)-10 - 80 °C
Overview
- Weight
- 48 g
- Colour
- Green
- Host interface
- PCIe
- Internal
- Yes
- Chipset
- PLX/Oxford - OXPCIe952
- Operating temperature (T-T)
- -10 - 80 °C
- Brand
- StarTech.com
- Category
- Interface Cards/Adapters
- Model
- PEX1S952LP
- Part number
- PEX1S952LP
- EAN / UPC
- 4058829151430, 065030835657, 112040007113, 132018237595 +11 more
- Also known as
- StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS
Specifications
36 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | Serial |
| Serial ports quantity | 1 |
| Serial interface type | RS-232 |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Green |
| Mean time between failures (MTBF) | 87600 h |
| Certification | CE, FCC, Microsoft WHQL, REACH |
Features
| Specification | Value |
|---|---|
| Chipset | PLX/Oxford - OXPCIe952 |
| Baud rate | 460.8 Kbit/s |
| FIFO (First In, First Out) | 128 B |
| Data bits | 4, 5, 6, 7, 8 |
| Stop bits | 1, 1.5, 2 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 80 °C |
| Storage temperature (T-T) | -20 - 100 °C |
| Operating relative humidity (H-H) | 5 - 85% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000 Professional, Windows 7, Windows 7 Ente |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported | Windows XP Embedded |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 65 mm |
| Depth | 90 mm |
| Height | 20 mm |
| Weight | 48 g |
Packaging data
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
| Drivers included | Yes |
| Manual | Yes |
| Package width | 144 mm |
| Package depth | 174 mm |
| Package height | 31 mm |
| Package weight | 130 g |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 75 pc(s) |
| Master (outer) case width | 357 mm |
| Master (outer) case length | 675 mm |
| Master (outer) case height | 312 mm |
