7 Port PCI USB Card Adapter - TAA
Model PCIUSB7EAN 898029629629
32 specifications
- Weight75 g
- ColourGreen
- Host interfacePCI/PCI-X
- InternalYes
- ChipsetVIA/VLI - VT6212
- Compliance certificatesRoHS
Overview
- Weight
- 75 g
- Colour
- Green
- Host interface
- PCI/PCI-X
- Internal
- Yes
- Chipset
- VIA/VLI - VT6212
- Compliance certificates
- RoHS
- Brand
- StarTech.com
- Category
- Interface Cards/Adapters
- Model
- PCIUSB7
- Part number
- PCIUSB7
- EAN / UPC
- 898029629629, 031112043449, 065030836531, 132018238134 +13 more
- Also known as
- StarTech.com 7 Port PCI USB Card Adapter - TAA
Specifications
32 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCI/PCI-X |
| Output interface | USB 2.0 |
| Expansion card standard | PCI 2.2 |
| USB 2.0 ports quantity | 4 |
| Internal USB 2.0 ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Green |
| Hot-swap | Yes |
| Certification | CE, FCC, TAA, REACH |
Features
| Specification | Value |
|---|---|
| Chipset | VIA/VLI - VT6212 |
| Plug and Play | Yes |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 122 mm |
| Height | 20 mm |
| Weight | 75 g |
Packaging data
| Specification | Value |
|---|---|
| Drivers included | Yes |
| Manual | Yes |
| Package width | 143 mm |
| Package depth | 174 mm |
| Package height | 33 mm |
| Package weight | 138 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
| Products per master (outer) case | 75 pc(s) |
| Master (outer) case width | 356 mm |
| Master (outer) case length | 686 mm |
| Master (outer) case height | 315 mm |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 480 Mbit/s |
