StarTech.com 24in Internal USB Motherboard Header to 2 Port Serial RS232 Adapter - TAA

StarTech.com 24in Internal USB Motherboard Header to 2 Port Serial RS232 Adapter - TAA

Model ICUSB232INT2EAN 6213759744314

35 specifications
  • Weight63 g
  • Host interfaceIDC
  • InternalYes
  • Baud rate115.2 Kbit/s
  • Operating temperature (T-T)-10 - 80 °C
  • Compliance certificatesRoHS
See all specifications

Overview

Weight
63 g
Host interface
IDC
Internal
Yes
Baud rate
115.2 Kbit/s
Operating temperature (T-T)
-10 - 80 °C
Compliance certificates
RoHS
Brand
StarTech.com
Model
ICUSB232INT2
Part number
ICUSB232INT2
EAN / UPC
6213759744314, 065030841528, 086000309572, 132017647142 +9 more
Also known as
StarTech.com 24in Internal USB Motherboard Header to 2 Port Serial RS232 Adapter - TAA

Specifications

35 specifications in 9 groups

Ports & interfaces

Host interfaceIDC
Output interfaceSerial
Serial ports quantity2
Serial interface typeRS-232

Design

InternalYes
CertificationMicrosoft WHQL, CE, FCC

Features

Baud rate115.2 Kbit/s
FIFO (First In, First Out)256 B
Data bits7, 8
Stop bits1, 2
Plug and PlayYes

Operational conditions

Operating temperature (T-T)-10 - 80 °C
Storage temperature (T-T)-20 - 100 °C
Operating relative humidity (H-H)5 - 85%

System requirements

Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Bas
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016

Technical details

Compliance certificatesRoHS

Weight & dimensions

Width120 mm
Depth68 mm
Height19 mm
Weight63 g

Packaging data

Mounting brackets includedYes
Drivers includedYes
ManualYes
Package width142 mm
Package depth174 mm
Package height33 mm
Package weight153 g

Logistics data

Harmonized System (HS) code84733020
Products per master (outer) case75 pc(s)
Master (outer) case width350 mm
Master (outer) case length693 mm
Master (outer) case height314 mm
