StarTech.com 2 Port RS232 PCI Express Serial Card
Model 2 Port RS232 PCI Express Serial CardPart no. PEX2S952PWEAN 650308457794
27 specifications
- ConnectivityWired
- Weight54 g
- ColourBlack
- Host interfacePCIe
- InternalYes
- ChipsetPLX OXPCIe952
Overview
- Connectivity
- Wired
- Weight
- 54 g
- Colour
- Black
- Host interface
- PCIe
- Internal
- Yes
- Chipset
- PLX OXPCIe952
- Brand
- StarTech.com
- Category
- Interface Cards/Adapters
- Model
- 2 Port RS232 PCI Express Serial Card
- Part number
- PEX2S952PW
- EAN / UPC
- 650308457794, 065030845779, 100177410937, 163120552863 +2 more
- Also known as
- StarTech.com 2 Port RS232 PCI Express Serial Card interface cards/adapter Internal
Specifications
27 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | Serial |
| Serial ports quantity | 2 |
| Serial interface type | RS-232 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Black |
| Certification | CE, FCC |
Features
| Specification | Value |
|---|---|
| Chipset | PLX OXPCIe952 |
| FIFO (First In, First Out) | 128 B |
Power
| Specification | Value |
|---|---|
| Power supply type | DC |
| Output voltage | 5, 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 85% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 15 mm |
| Depth | 80 mm |
| Height | 59 mm |
| Weight | 54 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 142 mm |
| Package depth | 170 mm |
| Package height | 30 mm |
| Package weight | 270 g |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Compatible operating systems | Windows 7 (32/64bit)/ Vista(32/64)/ XP(32/64)/ CE 5.0 Windows Server 2008 R2/ 2003(32/64)/ 2000 Linux 2.4.x/2.6.x |
| Electrostatic Discharge (ESD) protection | 15 kV |
