Manhattan 150972 interface cards/adapter Internal eSATA
Model 150972EAN 766623150972
21 specifications
- ConnectivityWired
- Weight34 g
- Host interfacePCIe
- InternalYes
- ChipsetMarvell M9128
- Compliance certificatesRoHS
Overview
- Connectivity
- Wired
- Weight
- 34 g
- Host interface
- PCIe
- Internal
- Yes
- Chipset
- Marvell M9128
- Compliance certificates
- RoHS
- Brand
- Manhattan
- Category
- Interface Cards/Adapters
- Model
- 150972
- Part number
- 150972
- EAN / UPC
- 766623150972
- Also known as
- Manhattan 150972 interface cards/adapter Internal eSATA
Specifications
21 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | eSATA |
| eSATA ports quantity | 2 |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Purpose | PC |
| Certification | FCC CE WEEE |
Features
| Specification | Value |
|---|---|
| Chipset | Marvell M9128 |
| Bandwidth | 6 Gbit/s |
| Logical block addressing (LBA) support | 48 bit |
| Native Command Queuing (NCQ) | Yes |
| RAID levels | 0, 1 |
| Plug and Play | Yes |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Ultimate, Windows Vista Business, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 122 mm |
| Depth | 68 mm |
| Height | 22 mm |
| Weight | 34 g |
Other features
| Specification | Value |
|---|---|
| Ports quantity | 2 |
| Connectivity technology | Wired |
