76619F interface cards/adapter Internal Serial
Model 76619FEAN 4043718348282
36 specifications
- Weight12 kg
- Host interfacePCIe
- InternalYes
- ChipsetCH382L
- Operating temperature (T-T)0 - 55 °C
- Width85 mm
Overview
- Weight
- 12 kg
- Host interface
- PCIe
- Internal
- Yes
- Chipset
- CH382L
- Operating temperature (T-T)
- 0 - 55 °C
- Width
- 85 mm
- Brand
- InLine
- Category
- Interface Cards/Adapters
- Model
- 76619F
- Part number
- 76619F
- EAN / UPC
- 4043718348282
- Also known as
- InLine 76619F interface cards/adapter Internal Serial
Specifications
36 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | Serial |
| Host interface gender | Male |
| Expansion card standard | PCIe 2.0 |
| Serial ports quantity | 2 |
| Serial interface type | RS-232, 9-pin |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Purpose | PC |
| Country of origin | Taiwan |
Features
| Specification | Value |
|---|---|
| Chipset | CH382L |
| Baud rate | 921.6 Kbit/s |
| FIFO (First In, First Out) | 256 B |
| Data bits | 5, 6, 7, 8 |
| Stop bits | 1, 2 |
| Full duplex | Yes |
| Parity bit | Even, Mark, No, Odd, Space |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1, Windows XP |
| Linux operating systems supported | Kernel 2.6, Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.19, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9, Linux Kernel 6.2, L |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2013, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), TÜV mark |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 85 mm |
| Depth | 1.26 mm |
| Height | 20 mm |
| Weight | 12 kg |
Packaging data
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
| Drivers included | Yes |
| Package width | 145 mm |
| Package depth | 150 mm |
| Package height | 30 mm |
| Package weight | 49 g |
| Package volume | 1000 cm³ |
| Package type | Hanging box |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 85 x 1.26 x 20 mm |
| Electrostatic Discharge (ESD) protection | 15 kV |
