76619E interface cards/adapter Internal Serial
Model 76619EEAN 4043718348275
36 specifications
- Weight2 kg
- Host interfacePCIe
- InternalYes
- ChipsetCH384L
- Operating temperature (T-T)0 - 55 °C
- Width100 mm
Overview
- Weight
- 2 kg
- Host interface
- PCIe
- Internal
- Yes
- Chipset
- CH384L
- Operating temperature (T-T)
- 0 - 55 °C
- Width
- 100 mm
- Brand
- InLine
- Category
- Interface Cards/Adapters
- Model
- 76619E
- Part number
- 76619E
- EAN / UPC
- 4043718348275
- Also known as
- InLine 76619E interface cards/adapter Internal Serial
Specifications
36 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | Serial |
| Host interface gender | Male |
| Expansion card standard | PCIe 2.0 |
| Serial ports quantity | 4 |
| Serial interface type | RS-232, 9-pin |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Purpose | PC |
| Country of origin | Taiwan |
Features
| Specification | Value |
|---|---|
| Chipset | CH384L |
| Baud rate | 921.6 Kbit/s |
| FIFO (First In, First Out) | 256 B |
| Data bits | 5, 6, 7, 8 |
| Stop bits | 1, 2 |
| Full duplex | Yes |
| Parity bit | Even, Mark, No, Odd, Space |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1, Windows XP |
| Linux operating systems supported | Kernel 2.6, Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.19, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9, Linux Kernel 6.2, L |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2013, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), TÜV mark |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 1.83 mm |
| Height | 120 mm |
| Weight | 2 kg |
Packaging data
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
| Drivers included | Yes |
| Package width | 125 mm |
| Package depth | 180 mm |
| Package height | 30 mm |
| Package weight | 90 g |
| Package volume | 700 cm³ |
| Package type | Box |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 100 x 1.83 x 120 mm |
| Electrostatic Discharge (ESD) protection | 15 kV |
