Dell LSI 9300-8e
Model LSI 9300-8ePart no. 406-BBDMEAN 4058154214770
18 specifications
- ColourGreen, Stainless steel
- Host interfacePCIe
- InternalYes
- Data transfer rate (max)8 Gbit/s
- Operating temperature (T-T)0 - 55 °C
- Compliance certificatesRoHS
Overview
- Colour
- Green, Stainless steel
- Host interface
- PCIe
- Internal
- Yes
- Data transfer rate (max)
- 8 Gbit/s
- Operating temperature (T-T)
- 0 - 55 °C
- Compliance certificates
- RoHS
- Brand
- Dell
- Category
- Interface Cards/Adapters
- Model
- LSI 9300-8e
- Part number
- 406-BBDM
- EAN / UPC
- 4058154214770, 5397063818372, 5712505746622, 7330381727153
- Also known as
- DELL LSI 9300-8e interface cards/adapter Internal SAS
Specifications
18 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCIe |
| Output interface | SAS |
| Expansion card form factor | Full-height / Low-profile |
| Expansion card standard | PCIe 3.0 |
| External mini-SAS ports | 8 |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Green, Stainless steel |
| Mean time between failures (MTBF) | 2800000 h |
| Certification | EMC: Class B-US (CFR 47, P15B), ICES-00, V-3/02.04, EN55022/EN55024, AS/NZS 3548, N-B 2-0001-404, EN60950, WEEE |
Features
| Specification | Value |
|---|---|
| Data transfer rate (max) | 8 Gbit/s |
| Bandwidth | 9.6 Gbit/s |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -45 - 105 °C |
| Operating relative humidity (H-H) | 5 - 90% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | FreeBSD 6.3, FreeBSD 7.0, RedHat EL Linux 3 U9, RedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, RedHat EL Linux 5.1, RedHat EL Linux 5.2, RedHat EL Linux 5.3, RedHat EL Linux 6.0, RedHat EL Linux 7.0, Solaris 10 U4, Solaris 10 U5, SuSE Linux 10, SuSE Linu |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Other features
| Specification | Value |
|---|---|
| Compatibility | PowerEdge R220 PowerEdge R320 PowerEdge R420 PowerEdge R520 PowerEdge R620 PowerEdge R630 PowerEdge R720 PowerEdge R720XD PowerEdge R730 PowerEdge R730XD PowerEdge R820 PowerEdge R920 PowerEdge T20 PowerEdge T320 PowerEdge T420 PowerEdge T620 PowerEdge T630 |
