Brainboxes USB 4 Port RS422/485 1MBaud

Brainboxes USB 4 Port RS422/485 1MBaud

Model US-346EAN 837324002096

34 specifications
  • Weight675 g
  • ColourBlack
  • Host interfaceUSB Type-B
  • InternalNo
  • Baud rate921.6 Kbit/s
  • Mac operating systems supportedYes
See all specifications

Overview

Weight
675 g
Colour
Black
Host interface
USB Type-B
Internal
No
Baud rate
921.6 Kbit/s
Mac operating systems supported
Yes
Brand
Brainboxes
Model
US-346
Part number
US-346
EAN / UPC
837324002096
Also known as
Brainboxes USB 4 Port RS422/485 1MBaud

Specifications

34 specifications in 8 groups

Ports & interfaces

Host interfaceUSB Type-B
Output interfaceSerial
USB 2.0 ports quantity1
Serial ports quantity4
Serial interface typeRS-422/485

Design

InternalNo
Product colourBlack
LED indicatorsYes
CertificationRoHS EMC CE AEO (C-TPAT)

Features

Baud rate921.6 Kbit/s
Data bits7, 8
Stop bits1, 2
Full duplexYes
Flow control supportYes
Parity bitEven, Mark, No, Odd, Space
Flow Control typeRTS/CTS, DTR/DSR, XON/XOFF
Export Control Classification Number (ECCN)4A994

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpris
Mac operating systems supportedYes
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2008, Windows Server 2008 x64

Technical details

Compliance certificatesFederal Communications Commission (FCC), CE, UKCA

Weight & dimensions

Width215 mm
Depth123 mm
Height34 mm
Weight675 g

Packaging data

Cables includedUSB Type-A to USB Type-B
Package width300 mm
Package depth135 mm
Package height80 mm
Package weight1.1 kg

Other features

Maximum operating distance1200 m
Compatible operating systemsWindows XP, Server 2003, Vista, Server 2008, Windows 7
SafetyIP-30
